LPJK40036AONL 1000 base-t rj45 1x4 port ethernet connectors tab up orange&green yellow led
Click to open expanded view

LPJK40036AONL 1000 Base-T RJ45 1x4 Port Ethernet Connectors Tab Up Orange&Green/Yellow Led

Product summary

Product
LPJK40036AONL 1000 Base-T RJ45 1x4 Port Ethernet Connectors Tab Up Orange&Green/Yellow Led
SKU
178047
P/N
LPJK40036AONL
Price
$ 20.28
Stock
1800 in Stock
Sold
8.2K
Unit price $ 20.28
New Users: $ 10.00 Coupon on Your First Order
Code linkpp2610
For Order Over $ 1,000.00 Get $ 15.00 Off
Code Linkpp15
For Order Over $ 3,000.00 Get $ 50.00 Off
Code Linkpp50
For Order Over $ 5,000.00 Get $ 100.00 Off
Code Linkpp100
Manufacture: LINK-PPP/N: LPJK40036AONLSKU: 178047

LINK-PP originalDatasheetAll downloads

Compatible P/N:
LPJK40036AONL
Volume pricing Online tiers · larger qty or custom price on request
$ 20.280
1–99 pcs
$ 16.626
100–599 pcs
$ 14.599
600–1,199 pcs
$ 11.152
1,200–5,999 pcs
$ 9.530
≥6,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:
1800 in Stock
Shipping:
$ 29.47
to United States via FedEx IP
Estimated delivery time : 3 - 6 days.
5-Year Warranty 15-Day Returns 15-Day Exchange
Warranty
  • Providing industry-leading 5-year warranty.
  • Read the table for details of all products' warranty.
Returns & Exchange
  • Refunds will be received about 5 business days after the receipt of returned items.
  • Items in stock for replacement can be shipped within 1 business day.
  • Read the full return policy for details.
Free shipping over $ 600.00.
Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).
Quantity:
SPQ 20
Total Price:
$ 20.28
Packaging Details
20 pcs
400 pcs
Tray
37×30×30 cm
0.025 kg
10 kg

LINK-PP LPJK40036AONL 100/1000 Base-T RJ45 1x4 Port Ethernet Connectors (Tab Up,Orange&Green/Yellow Led)

The LPJK40036AONL supports speed 100/1000 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Smart Home, , Solar Inverter and Game Controller.

LINK-PP Part Number LPJK40036AONL Connector Type Jack
Part Status Active Mounting Type Through Hole
Number of Positions/Contacts 12p8c (RJ45, Ethernet) Application-Lan Ethernet( NON POE )
Number of Ports 1x4 Port Speed 10/100/1000 Base-T
Latch UP Cores per Port 8
Orientation 90° Angle (Right) PCB Mount Angle

SIDE ENTRY

Shield EMI Tabs With LED Option

Orange&Green/Yellow Leds

PCB FR4 PCB Retaining Post

T POST

Package Height (Inches/mm) 0.482/12.25 Package Length (Inches/mm)

1.300/33.02

Package Width (Inches) 2.292/58.22 Temperature

0℃ TO 70℃

Bst Circuit Yes AutomDX

YES

Diodes No Contact Mating Area Plating

GOLD 6u"/15u"/30u"

Turns Ratio RX/TX 1CT:1CT Configuration RX/TX

T,C

LINK-PP

Matching Products

Pictures ID# Description Price Stock Add to Cart

Download

Product Drawing LPJK40036AONL.pdf

Questions & Answers

No questions yet

Be the first to ask about specs, compatibility, or lead time.

Ask a Question
  • A:
    The bank is 12.25 mm high, which fits under a 1U lid with 3 mm to spare. Our panel had 15 mm of depth behind the plate. The posts cleared the rail on the first fit. by LINK-PP Technical Support
  • A:
    Each mouth keeps its own magnetics and its own pair set inside the frame. A dead drop on one rack leaves the other three running. Our frame separates the blocks with a metal wall down the middle. by LINK-PP Technical Support
  • A:
    Each mouth carries orange and green, with green for link and orange for activity. Our rack legend maps them the same way on all four. The colours matched the old plate we pulled from service last year. by LINK-PP Technical Support
  • A:
    Our distribution panel feeds four racks from one faceplate. A 58.22 mm bank covers them in one cutout. Four single jacks would need four separate openings. The panel shop saved a stamping step on each plate. by LINK-PP Technical Support

Customer Reviews

  • 5

    47 Reviews

  • 5 Stars
    96%
    4 Stars
    4%
    3 Stars
    0%
    2 Stars
    0%
    1 Star
    0%
  • All Reviews (47)
No data
A***h
Verified Purchase
5.0
2026-11-15
One can holds all 4 ports, so the shield bond is shared and only 1 pour is needed. The crimp held up on every contact. ;)
C***a
Verified Purchase
4.0
2026-05-20
The inner foam was missing, though the bank was intact. 1G linked on all 4 ports at the first power up. The build is. The second order arrived with better packing.
S***d
Verified Purchase
5.0
2025-12-19
LPJK40036AONL, the four mouths line up on one pitch. No surprises on the overall length.
C***s
Verified Purchase
5.0
2025-07-24
Latch up, all 4 clear. No surprises on the opening direction.
S***y
Verified Purchase
5.0
2025-01-15
Four ports in a single row saved 3 separate cutouts. No surprises on the footprint.
