LP24AC01301 sfp 2x4 cage assembly with integrated connector with outer light pipe

LP24AC01301 SFP 2x4 Cage Assembly With Integrated Connector With Outer Light Pipe

Product summary

Product
LP24AC01301 SFP 2x4 Cage Assembly With Integrated Connector With Outer Light Pipe
SKU
170490
P/N
LP24AC01301
Price
$ 11.80
Stock
5000 in Stock
Sold
5.5K
Unit price $ 11.80
New Users: $ 10.00 Coupon on Your First Order
Code linkpp2610
For Order Over $ 1,000.00 Get $ 15.00 Off
Code Linkpp15
For Order Over $ 3,000.00 Get $ 50.00 Off
Code Linkpp50
For Order Over $ 5,000.00 Get $ 100.00 Off
Code Linkpp100
P/N: LP24AC01301SKU: 170490

LINK-PP originalDatasheet3D ModelAll downloads

Compatible:
LINK-PP
Compatible P/N:
LP24AC01301
Volume pricing Online tiers · larger qty or custom price on request
$ 11.800
1–99 pcs
$ 10.114
100–999 pcs
$ 8.850
1,000–4,999 pcs
$ 8.408
5,000–9,999 pcs
$ 7.965
≥10,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:
5000 in Stock
Shipping:
$ 29.47
to United States via FedEx IP
Estimated delivery time : 3 - 6 days.
5-Year Warranty 15-Day Returns 15-Day Exchange
Warranty
  • Providing industry-leading 5-year warranty.
  • Read the table for details of all products' warranty.
Returns & Exchange
  • Refunds will be received about 5 business days after the receipt of returned items.
  • Items in stock for replacement can be shipped within 1 business day.
  • Read the full return policy for details.
Free shipping over $ 99.00.
Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).
Quantity:
Total Price:
$ 11.80

LINK-PP LP24AC01301 SFP 2x4 Cage Assembly With Integrated Connector With Outer Light Pipe

LINK-PP Part Number LP24AC01301 Part Status Active
Product Type Cage Assembly with Integrated Connector Form Factor SFP
Max Data Rate 4 Gbps Features EMI Shielded
Port Matrix Configuration 2×4 Number of Ports 8
Included Connector Yes Included Heat Sink No
Included Lightpipe Yes EMI Containment Feature Type Spring Fingers
Termination Press-Fit Mounting Type Through Hole, Right Angle
Tail Length (Inches/mm) 0.106/2.70 Recommended PCB Thickness (Inches/mm) 0.093/2.36
Length (Inches/mm) 2.490/63.25 (REF) Width (Inches/mm) 2.254/57.25 (REF)
Height (Inches/mm) 1.016/25.80 (REF) Cage Material Stainless Steel
Contact Plating Gold Cage Plating Nickel
Operating Temperature Range -40 to +85°C Packaging Tray

Model Comparison Table

LINK-PP

Matching Products

Pictures ID# Description Price Stock Add to Cart

Download

Product Drawing LP24AC01301-Drawing.pdf

Questions & Answers

No questions yet

Be the first to ask about specs, compatibility, or lead time.

Ask a Question
  • A:
    Tray packing is how we ship this 2x4 cage to the line. Press-fit tails enter the board after the SMT oven pass. The LCP housing is not rated for a second reflow cycle. Where that press station lands depends on your assembly sequence. by LINK-PP Technical Support
  • A:
    Our -40 to 85 C figure is written for the cage and its LCP housing. A pluggable module carries a temperature grade of its own. 2 warm transceivers in a ganged shell also share one air volume. We would read the module grade alongside your cabinet thermal numbers. by LINK-PP Technical Support
  • A:
    We fit one outer pipe above the upper row of this cage. The drawing assigns no separate lens to each of the 8 mouths. An emitter placed for a 1x1 footprint does not line up with it. Your front artwork and the board LED map settle that register. by LINK-PP Technical Support
  • A:
    The LP24AC01301 body measures 63.25 mm across the front face. Eight mouths sit in a 2x4 matrix with one shared cavity. A bezel cut below that width pinches the outer 2 latches. We would compare the outline against your panel draft before tooling. by LINK-PP Technical Support
