The LINK-PP LS-BL49551G-80I 1G BiDi transceiver provides 1.25 Gbps connectivity via single-mode fiber with a reach of up to 80 km. It operates at a wavelength pair of 1490nm-TX/1550nm-RX. Built to industrial standards, the transceiver delivers reliable performance for robust long-haul transmission under demanding environmental conditions.
| LINK-PP Part Number | LS-BL49551G-80I | Vendor Name | LINK-PP |
| Form Factor | SFP | Max Data Rate | 1.25Gbps |
| Wavelength | 1490nm-TX/1550nm-RX | Max Cable Distance | 80km |
| Connector | Simplex LC | Media | SMF |
| Transmitter Type | DFB BiDi | Receiver Type |
PIN |
| TX Power | 0 to +5dBm | RX Power | -26 to -1dBm |
| Receiver Sensitivity | <-26dBm | Receiver Overload | -1dBm |
| Operating Temperature Range | -40 to 85°C | Protocols |
Fast Ethernet, Gigabit Fibre Channel, MSA Compliant |
The LINK-PP LS-BL49551G-80I 1G BiDi SFP module offers 1.25 Gbps reliable throughput and true plug-and-play capability for seamless deployment. With a DFB laser, PIN/TIA receiver, simplex LC port, and DOM, it supports full-duplex transmission over a single fiber via BiDi technology, boosting fiber usage while lowering cabling costs and complexity.
Single-fiber bidirectional communication is made possible by matching TX/RX wavelengths. This compact 1G BiDi SFP boosts network capacity without adding fiber.
The LINK-PP LS-BL49551G-80I delivers stable 1.25 Gbps for Gigabit Ethernet and fiber channel, with low latency, consistent throughput, and reliable connectivity for enterprise, telecom, and industrial systems.
The optimized 1490nm transmitter (TX) and 1550nm receiver (RX) wavelengths of the LINK-PP LS-BL49551G-80I BiDi SFP optical module deliver low-interference, high-integrity, bidirectional communication over a single fiber for long-haul deployments.
This LINK-PP LS-BL49551G-80I 1G BiDi SFP module handles transmission distances up to 80 km over standard single-mode fiber, making it a perfect fit for long-haul deployments like metro networks, campus interconnects, and remote site links, with no extra signal repeaters needed.
Integrating Tx and Rx into a single LC port, this simplified fiber setup reduces installation time, lowers costs, and is especially advantageous in fiber-limited environments.
The LINK-PP LS-BL49551G-80I BiDi module leverages advanced DOM capabilities to monitor vital metrics in real time, helping optimize performance and accelerate fault detection.
The LINK-PP module is manufactured under stringent ISO 9001 quality control and is CE, RoHS, and FCC certified, ensuring constant and trustworthy optical performance.
Thorough testing ensures each module delivers consistent accuracy and long-term dependability.
LINK-PP modules are developed and certified to deliver high stability, reliability, and compliance with international standards.
Seamlessly integrates with LINK-PP-compatible devices, ensuring fast setup and reliable operation.
Strict testing standards guarantee consistent signal quality and long-term performance. For further information, see the LINK-PP Test Support Center.
Verifies exact wavelength accuracy to meet the highest optical standards.
Ensures excellent waveform clarity for superior performance.
Delivers consistently low error rates for mission-critical applications.
Proven to perform reliably across rigorous environmental demands.
LINK-PP carefully manages every step from packaging to delivery, ensuring each module arrives safely through trusted international logistics.
Static-dissipative packaging safeguards delicate electronic parts.
Impact-resistant design prevents damage throughout shipping.
Quick order fulfillment ensures timely dispatch.
International shipping services guarantee reliable worldwide delivery.
The LINK-PP LS-BL49551G-80I module provides consistent 1.25 Gbps speed over distances of up to 80 km, making it ideal for connecting remote network nodes, extending enterprise LANs, and supporting telecom backhaul. For example, it can link two data centers across a city using a single fiber strand, significantly reducing infrastructure costs.
LINK-PP provides professional technical support, including pre-sales consultation, compatibility verification, and post-deployment troubleshooting to ensure smooth network operation.
Professional technical guidance to help customers select the most suitable LS-BL49551G-80I modules based on network architecture and application requirements.
Compatibility checks and validation to ensure seamless operation with Cisco switches and other supported networking platforms.
Step-by-step support for installation, configuration, and initial deployment to ensure stable and correct operation.
Ongoing technical support throughout the product lifecycle to ensure reliable performance in enterprise and carrier-grade networks.
LINK-PP provides after-sales support for the smooth deployment and reliable operation of the optical modules.
15-day no-reason return and refund
Free replacement for dead-on-arrival (DOA) or defective items within the initial period
Free repair services for manufacturing defects throughout the warranty period
Warranty exclusions and conditions apply
Compatible | LINK-PP | LINK-PP | LINK-PP | LINK-PP | LINK-PP | LINK-PP |
Data Rate (Max) | 1.25Gbps | 1.25Gbps | 1.25Gbps | 1.25Gbps | 1.25Gbps | 1.25Gbps |
Wavelength | 1490nm-TX/1550nm-RX | 1490nm-TX/1550nm-RX | 1490nm-TX/1550nm-RX | 1550nm-TX/1490nm-RX | 1490nm-TX/1550nm-RX | 1490nm-TX/1550nm-RX |
Connector | Simplex LC | Simplex LC | Simplex LC | Simplex LC | Simplex LC | Simplex LC |
Cable Distance (Max) | 80km | 150km | 160km | 10km | 100km | 120km |
Cable Type | SMF | SMF | SMF | SMF | SMF | SMF |
TX Power | 0 to +5dBm | 0 to +5dBm | 0 to +5dBm | 0 to +5dBm | 0 to +5dBm | 0 to +5dBm |
Receiver Sensitivity | -26 to -1dBm | -28 to -1dBm | -28 to -1dBm | -26 to -1dBm | -28 to -1dBm | -28 to -1dBm |
Operating Temperature | -40 to 85°C | -40 to 85°C | -40 to 85°C | -40 to 85°C | -40 to 85°C | -40 to 85°C |
Form Factor | SFP | SFP | SFP | SFP | SFP | SFP |
Transmitter Type | DFB BiDi | DFB | DFB | DFB | DFB BiDi | DFB BiDi |
Receiver Type | PIN | APD | APD | PIN | PIN | APD |
Receiver Overload | -1dBm | -1dBm | -6dBm | |||
Protocols | Fast Ethernet, Gigabit Fibre Channel, MSA Compliant | Fast Ethernet, Gigabit Fibre Channel, MSA Compliant | SFP MSA、SFF-8472 | Fast Ethernet, Gigabit Fibre Channel, MSA Compliant | Fast Ethernet, Gigabit Fibre Channel, MSA Compliant | Fast Ethernet, Gigabit Fibre Channel, MSA Compliant |
| Pictures | ID# | Description | Price | Stock | Add to Cart |
Q: Are these LINK-PP LS-BL49551G-80I industrial transceivers fully rated for extreme outdoor temperatures (-40°C to +85°C), or are they just standard commercial units with a fancy label? By S***z on 2025-03-11
A: These are true industrial-grade (I-Temp) transceivers designed with hardened laser diodes, IC components, and PCB layouts specifically built to operate reliably in harsh environments ranging from -40°C to +85°C, making them ideal for outdoor cabinets and remote base stations. By admin on 2025-03-11
Q: What is the exact optical power budget and typical receiving sensitivity for this 80km 1G BiDi module? We need to verify our link loss margin. By L***k on 2024-02-25
A: The transmitter optical power (TX) ranges from 0dBm to +5dBm, and the receiver sensitivity (RX) is -26dBm to -1dBm, which comfortably supports stable transmission up to 80km over standard Single-Mode Fiber (SMF). By admin on 2024-02-25
Q: Does this industrial SFP module support real-time Digital Diagnostic Monitoring (DOM/DDM) so our NOC team can track core temperature and optical levels? By G***s on 2024-02-03
A: Absolutely. The LS-BL49551G-80I features built-in DDM/DOM functionality compliant with SFF-8472 standards. You can monitor real-time parameters such as internal transceiver temperature, laser bias current, TX power, and RX power directly through your switch command-line interface. By admin on 2024-02-03
