A70-112-331N126 EDAC Compatible LINK-PP LPJG0926HENL 100/1000 Base-T RJ45 PoE+ Gigabit Magnetics Jack for Intercom and SMPS (POE+, Single Port, Tab Down, Green/Yellow Led)
Looking for the EDAC A70-112-331N126 single-port RJ45 connector for your manufacturing line or embedded hardware design? The LINK-PP LPJG0926HENL is engineered as a direct drop-in compatible replacement for the EDAC A70-112-331N126, offering identical mechanical dimensions, electrical schematics, and signal integrity.
This product is fully compatible with the EDAC A70-112-331N126 part number, making it an ideal, layout-free alternative for Raspberry Pi Compute Module 4 IO Board (CM4IO) developers, industrial PC (IPC) manufacturers, smart intercom designers, and power supply (SMPS) systems. By utilizing this A70-112-331N126 compatible magjack, you can keep your production lines moving without any PCB redesign or schematic modifications.
Cross-Reference & Compatibility Overview:
- Primary Target P/N: EDAC A70-112-331N126
- Compatible Replacement P/N: LINK-PP LPJG0926HENL (SKU: 88517)
- Application Match: 100% pin-to-pin replacement on the official Raspberry Pi CM4IO board, which natively specifies the EDAC A70-112-331N126.
| LINK-PP Part Number |
LPJG0926HENL |
EDAC Part Number |
A70-112-331N126 |
| Part Status |
Active |
Connector Type |
Jack |
| Number of Positions/Contacts |
10p8c (RJ45, Ethernet) |
Application-Lan |
Ethernet(PoE+) |
| Number of Ports |
1x1 Port |
Speed |
10/100/1000 Base-T |
| Latch |
Down |
Cores per Port |
8 |
| Orientation |
90° Angle (Right) |
PCB Mount Angle |
SIDE ENTRY
|
| Shield EMI Tabs |
Without |
LED Option |
Green/Yellow
|
| PCB |
FR4 |
PCB Retaining Post |
T POST
|
| Package Height (Inches/mm) |
0.524/13.30 |
Package Length (Inches/mm) |
0.837/21.25
|
| Package Width (Inches/mm) |
0.627/15.93 |
Temperature |
0℃ TO 70℃
|
| Bst Circuit |
Yes |
AutomDX |
YES
|
| Diodes |
No |
Contact Mating Area Plating |
GOLD 6u"/15u"/30u"
|
| Turns Ratio RX/TX |
1CT:1CT |
Configuration RX/TX |
T,C
|
Exhaustive Technical Specifications (A70-112-331N126 Equivalent):
1. Electrical Performance & LAN Magnetics:
- Speed Capability: Gigabit Ethernet (10/100/1000 Base-T) for high-speed network transmission.
- PoE Standard: Compliant with IEEE 802.3at (PoE+) standard, delivering up to 30W of power.
- Inductance (OCL): 350uH Minimum at 100KHz, 0.1V with 8mA DC Bias.
- Turns Ratio (TX/RX): 1CT:1CT Transmitter / 1CT:1CT Receiver, ensuring balanced signal transformation.
- Isolation Voltage: 1500Vrms minimum, protecting downstream ICs and microcontrollers.
2. Mechanical & Physical Interface:
- Orientation: 90-degree Right Angle, Side Entry.
- Mounting Type: Through-Hole (THT) Solder mounting pins for robust mechanical attachment to the PCB.
- Latch Direction: Latch Down (Tab Down) configuration.
- LED Configuration: Dual LED indicators (Left: Green, Right: Yellow) for real-time link and activity status monitoring.
- Shielding Structure: Copper alloy shield with solder tail pins; designed without EMI Tab contacts, matching the exact physical envelope of the EDAC A70-112-331N126.
- Overall Dimensions: Width: 15.93 mm, Height: 13.30 mm, Length/Depth: 21.25 mm.
3. Materials & Environmental Standards:
- Housing Material: Thermoplastic, UL 94V-0 rated (black).
- Contact Plating: Gold plating over nickel on mating area for low contact resistance and long cycle life.
- Operating Temperature: Rated for standard commercial operating temperature range (0°C to 70°C).
- Compliance: Compliant with global environmental and safety directives: UL Certified, RoHS Directive, REACH Compliant, manufactured under ISO9001 and ISO14001 certified quality control systems.
Key Benefits of the LINK-PP A70-112-331N126 Compatible Solution:
- Zero PCB Redesign: The physical footprint, pin layout, and LED positions are identical to the EDAC A70-112-331N126. Hardware design engineers can seamlessly swap the component during assembly without updating Altium, Eagle, or KiCad footprint libraries.
- Reliable Component Sourcing: Avoid supply chain delays and long lead times for EDAC components. LINK-PP maintains standard stock levels to ensure stable delivery times for mass production orders.
- Optimized for SMT/THT Assembly: Packaged in secure, anti-static trays (50 pieces per tray, 1000 pieces per master carton) compatible with manual insertion and wave soldering production lines.
Sample & Engineering Support:
Technical data sheets, 2D mechanical drawings, 3D STP CAD files, and free engineering prototype samples of this A70-112-331N126 compatible magjack are available upon request. Contact our sales engineering team to verify your hardware cross-reference list and secure your volume quotation.
