LP22AC01101 sfp 2x2 cage&connector press-fit with inner outer light pipe
Click to open expanded view

LP22AC01101 SFP 2x2 Cage&Connector Press-Fit With Inner/Outer Light Pipe

Product summary

Product
LP22AC01101 SFP 2x2 Cage&Connector Press-Fit With Inner/Outer Light Pipe
SKU
170631
P/N
LP22AC01101
Price
$ 6.27
Stock
5000 in Stock
Sold
100
Unit price $ 6.27
New Users: $ 10.00 Coupon on Your First Order
Code linkpp2610
For Order Over $ 1,000.00 Get $ 15.00 Off
Code Linkpp15
For Order Over $ 3,000.00 Get $ 50.00 Off
Code Linkpp50
For Order Over $ 5,000.00 Get $ 100.00 Off
Code Linkpp100
P/N: LP22AC01101SKU: 170631

LINK-PP originalDatasheetAll downloads

Compatible:
LINK-PP
Compatible P/N:
LP22AC01101
Volume pricing Online tiers · larger qty or custom price on request
$ 6.270
1–99 pcs
$ 5.371
100–999 pcs
$ 4.700
1,000–4,999 pcs
$ 4.465
5,000–9,999 pcs
$ 4.230
≥10,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:
5000 in Stock
Shipping:
$ 29.47
to United States via FedEx IP
Estimated delivery time : 3 - 6 days.
5-Year Warranty 15-Day Returns 15-Day Exchange
Warranty
  • Providing industry-leading 5-year warranty.
  • Read the table for details of all products' warranty.
Returns & Exchange
  • Refunds will be received about 5 business days after the receipt of returned items.
  • Items in stock for replacement can be shipped within 1 business day.
  • Read the full return policy for details.
Free shipping over $ 99.00.
Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).
Quantity:
Total Price:
$ 6.27

LINK-PP LP22AC01101 SFP 2x2 Cage Connector Press-Fit With Inner/Outer Light Pipe

LINK-PP Part Number LP22AC01101 Part Status Active
Product Type Cage Form Factor SFP
Cage COPPER ALLOY,Ni PL ATED PACKAGING TRAY PACKAGING
Port Matrix Configuration 2x2 Port Number of Ports 4
Operating Temperature Range -40 – 85°C Mounting Style Through Hole, Right Angle
Included Lightpipe Inner/Outer Light Pipe Termination Press-Fit
Height (Inches/mm) 0.992/25.20 Length (Inches/mm) 2.490/63.25
Width (Inches/mm) 1.132/28.75 EMI Containment Feature Type
EMI Springs

Model Comparison Table

LINK-PP

Matching Products

Pictures ID# Description Price Stock Add to Cart

Download

Product Drawing LP22AC01101.pdf

Questions & Answers

No questions yet

Be the first to ask about specs, compatibility, or lead time.

Ask a Question
  • A:
    Spring fingers run around the rim of each of the 4 openings. Bare metal at the chassis cutout is what they press against. A painted band gives those fingers no conductive return. The masking note belongs on your bezel drawing. by LINK-PP Technical Support
  • A:
    These tails are formed for plated holes, not solder paste. The housing sits in trays until the board has cleared reflow. A second oven pass is outside the LCP rating we publish. Where the press station falls depends on your line sequence. by LINK-PP Technical Support
  • A:
    This 2x2 cage carries two pipe runs, one inside the shell and one outside. Each run ends above its own row of openings. A board LED placed for a 1x1 cage lines up with neither. Your LED map and front artwork fix those two positions. by LINK-PP Technical Support
  • A:
    Two rows of two openings share this nickel plated shell. The published face is 28.75 mm wide by 25.20 mm high. A cutout drawn for a 2x1 cage leaves the lower row exposed. Your panel drawing carries the final opening size. by LINK-PP Technical Support

Customer Reviews

  • 5

    23 Reviews

  • 5 Stars
    96%
    4 Stars
    4%
    3 Stars
    0%
    2 Stars
    0%
    1 Star
    0%
  • All Reviews (23)
No data
A***d
Verified Purchase
5.0
2026-11-13
The nickel finish held up through 2 rework cycles.
G***t
France
Verified Purchase
5.0
2026-02-12
Four cages in one block, a clean fit on the line card.
B***d
New Zealand
Verified Purchase
5.0
2025-08-29
The springs between the rows kept crosstalk low, a clean result.
G***n
Romania
Verified Purchase
5.0
2025-02-18
Pressed in first try.
E***a
Sweden
Verified Purchase
4.0
2024-03-22
One tray came in with 2 bent corners, but every cage pressed down flat. All four mouths took a module and the light pipes lined up with the panel windows. Solid metalwork.
