Pulse JX80-0019NL Compatible LINK-PP LPJ26404AFNL 10/100 Base-T 8p8c Tab Down Green/Green LED 1x2 Port RJ45 Jack

Name: Pulse JX80-0019NL Compatible LINK-PP LPJ26404AFNL 10/100 Base-T 8p8c Tab Down Green/Green LED 1x2 Port RJ45 Jack
Brand: LINK-PP
SKU: 100288
Price: 4.85 USD
Availability: InStock
Rating: 5 (8 reviews)

Product: Pulse JX80-0019NL Compatible LINK-PP LPJ26404AFNL 10/100 Base-T 8p8c Tab Down Green/Green LED 1x2 Port RJ45 Jack
SKU: 100288
P/N: LPJ26404AFNL
Price: $ 4.85
Stock: 1540 in Stock
Sold: 6.2K
Product URL: https://www.l-p.com/products/436275.htm

8 Reviews

4 Questions

6.2KSold

Unit price $ 4.85

New Users: $ 10.00 Coupon on Your First Order

Code linkpp2610

For Order Over $ 1,000.00 Get $ 15.00 Off

Code Linkpp15

For Order Over $ 3,000.00 Get $ 50.00 Off

Code Linkpp50

For Order Over $ 5,000.00 Get $ 100.00 Off

Code Linkpp100

Manufacture: LINK-PPP/N: LPJ26404AFNLSKU: 100288

Compatible with Pulse JX80-0019NLDatasheet 3D Model All downloads

Compatible:: LINK-PP; Pulse; X Multiple

Compatible P/N:: JX80-0019NL

Volume pricing Online tiers · larger qty or custom price on request

$ 4.850

1–99 pcs

$ 3.977

100–599 pcs

$ 3.492

600–1,199 pcs

$ 2.668

1,200–5,999 pcs

$ 2.280

≥6,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:

1540 in Stock

Shipping:

$ 29.47

to United States via FedEx IP

Estimated delivery time : 3 - 6 days.

5-Year Warranty 15-Day Returns 15-Day Exchange

Free shipping over $ 600.00.

Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).

Quantity:

SPQ 30

Total Price:

$ 4.85

Packaging Details

SPQ:30 pcs
Qty/carton:600 pcs
Package:Tray
Carton size:37×30×30 cm
N.W/pcs:0.015 kg
G.W/carton:9 kg

Description
Specification
Matching Products
Download
Q&A
Customer Reviews

Pulse JX80-0019NL Compatible LINK-PP LPJ26404AFNL 10/100 Base-T RJ45 Jack for Network Card and Switching Power (1x2 Port , Tab Down,Green/Green LED)

The LPJ26404AFNL supports speed 10/100 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Network Card, Optical Terminal ,Webcams and Switching Power.

LINK-PP Part Number:	LPJ26404AFNL	Pulse Part Number	JX80-0019NL
Part Status	Active	Connector Type	Jack
Number of Positions/Contacts	8p8c (RJ45, Ethernet)	Application-Lan	Ethernet(NoN PoE)
Number of Ports	1x2 Port	Speed	10/100 Base-T
Latch	Down	Cores per Port	4
Orientation	90° Angle (Right)	PCB Mount Angle	SIDE ENTRY
Shield EMI Tabs	With	LED Option	Green/Green
PCB	FR4	PCB Retaining Post	T POST
Package Height (Inches/mm)	0.536/13.61	Package Length (Inches/mm)	0.841/21.36
Package Width (Inches/mm)	1.228/31.18	Temperature	-40℃ TO 85℃
Bst Circuit	Yes	AutomDX	YES
Diodes	No	Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Turns Ratio RX/TX	1CT:1CT	Configuration RX/TX	T,C
