Tyco 5-6605433-8 Compatible LINK-PP LPJG0806GENL 100/1000 Base-T Single Port Ethernet RJ45 Magnetic Jack Tab Down Green/Yellow Led

Name: Tyco 5-6605433-8 Compatible LINK-PP LPJG0806GENL 100/1000 Base-T Single Port Ethernet RJ45 Magnetic Jack Tab Down Green/Yellow Led
Brand: LINK-PP
SKU: 87377
Price: 2.95 USD
Availability: InStock
Rating: 5 (76 reviews)

Product: Tyco 5-6605433-8 Compatible LINK-PP LPJG0806GENL 100/1000 Base-T Single Port Ethernet RJ45 Magnetic Jack Tab Down Green/Yellow Led
SKU: 87377
P/N: LPJG0806GENL
Price: $ 2.95
Stock: 3600 in Stock
Sold: 20K
Product URL: https://www.l-p.com/products/431679.htm

76 Reviews

4 Questions

20KSold

Unit price $ 2.95

New Users: $ 10.00 Coupon on Your First Order

Code linkpp2610

For Order Over $ 1,000.00 Get $ 15.00 Off

Code Linkpp15

For Order Over $ 3,000.00 Get $ 50.00 Off

Code Linkpp50

For Order Over $ 5,000.00 Get $ 100.00 Off

Code Linkpp100

Manufacture: LINK-PPP/N: LPJG0806GENLSKU: 87377

Compatible with Tyco 5-6605433-8Datasheet 3D Model All downloads

Compatible:: Tyco; LINK-PP

Compatible P/N:: C-5-6605433-8; 5-6605433-8

Volume pricing Online tiers · larger qty or custom price on request

$ 2.950

1–99 pcs

$ 2.422

100–599 pcs

$ 2.127

600–1,199 pcs

$ 1.625

1,200–5,999 pcs

$ 1.388

≥6,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:

3600 in Stock

Shipping:

$ 29.47

to United States via FedEx IP

Estimated delivery time : 3 - 6 days.

5-Year Warranty 15-Day Returns 15-Day Exchange

Free shipping over $ 600.00.

Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).

Quantity:

SPQ 50

Total Price:

$ 2.95

Packaging Details

SPQ:50 pcs
Qty/carton:1200 pcs
Package:Tray
Carton size:32×30×31 cm
N.W/pcs:0.008 kg
G.W/carton:9 kg

Description
Specification
Matching Products
Download
Q&A
Customer Reviews

Tyco 5-6605433-8 Compatible LINK-PP LPJG0806GENL 100/1000 Base-T Ethernet RJ45 Magnetic Jack for Monitoring System and Embedded Main Board (Single Port, Tab Down, Green/Yellow Led)

The LPJG0806GENL supports speed 100/1000 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Monitoring System, Embedded Main Board, Video Recorder and Smart Meters.

LINK-PP Part Number:	LPJG0806GENL	Tyco Part Number	5-6605433-8
Part Status	Active	Connector Type	Jack
Number of Positions/Contacts	10p8c (RJ45, Ethernet)	Application-Lan	Ethernet(NoN PoE)
Number of Ports	1x1 Port	Speed	10/100/1000 Base-T
Latch	Down	Cores per Port	8
Orientation	90° Angle (Right)	PCB Mount Angle	SIDE ENTRY
Shield EMI Tabs	With	LED Option	Green/Yellow
PCB	FR4	PCB Retaining Post	T POST
Package Height (Inches/mm)	0.528/13.40	Package Length (Inches/mm)	0.839/21.30
Package Width (Inches/mm)	0.626/15.90	Temperature	0℃ TO 70℃
Bst Circuit	Yes	AutomDX	YES
Diodes	No	Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Turns Ratio RX/TX	1CT:1CT	Configuration RX/TX	T,C

RJ45 Magnetic Jack
