Netgear CWDM-SFP-1290 Compatible LINK-PP 1.25G SFP CWDM Optical Transceiver Module(1290nm,80km,SMF,Duplex LC,DDM) The Netgear CWDM-SFP-1290 Compatible LINK-PP SFP transceiver is high performance, cost effective modules supporting data rate of 1.25Gbps and 80km transmission distance with SMF. The transceiver consists of three sections: a CWDM DFB laser transmitter, a PIN photodiode integrated with atrans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472

Netgear CWDM-SFP-1310 Compatible LINK-PP 1.25G SFP CWDM Single Mode Optical Transceiver Module(1310nm,40km,DOM,Duplex LC/UPC) The Netgear CWDM-SFP-1310 Compatible LINK-PP SFP transceivers are high performance, cost effective modules supporting data rate of 1.25Gbps and 40km transmission distance with SMF.The transceiver consists of three sections: a CWDM DFB laser transmitter, a PIN photodiode integrated with atrans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The Netgear CWDM-SFP-1310 Compatible

Netgear CWDM-SFP-1390 Compatible LINK-PP 1.25G SFP CWDM Optical Transceiver Module(1390nm,80km,SMF,Duplex LC,DDM) The Netgear CWDM-SFP-1390 Compatible LINK-PP SFP transceiver is high performance, cost effective modules supporting data rate of 1.25Gbps and 80km transmission distance with SMF. The transceiver consists of three sections: a CWDM DFB laser transmitter, a PIN photodiode integrated with atrans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472

Netgear CWDM-SFP-1390 Compatible LINK-PP 1.25G SFP CWDM Single Mode Optical Transceiver Module(1390nm,40km,DOM,Duplex LC) The Netgear CWDM-SFP-1390 Compatible LINK-PP is a high-performance, cost-efficient SFP transceiver designed for single-mode fiber networks. It delivers a data rate of 1.25Gbps with a transmission distance of up to 40km. Built with a CWDM DFB laser transmitter, a PIN photodiode with integrated TIA, and an MCU control module, this unit complies with Class 1 laser safety standards and supports SFP MSA and SFF-8472 digital diagnostic monitoring.   Netgear Part

Netgear CWDM-SFP-1450 Compatible LINK-PP 1.25G SFP CWDM Optical Transceiver Module(1450nm,80km,SMF,Duplex LC,DDM) The Netgear CWDM-SFP-1450 Compatible LINK-PP SFP transceiver is high performance, cost effective modules supporting data rate of 1.25Gbps and 80km transmission distance with SMF. The transceiver consists of three sections: a CWDM DFB laser transmitter, a PIN photodiode integrated with atrans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472

Netgear CW-SFP10G80-51-I Compatible LINK-PP 10G SFP+ CWDM Optical Transceiver Module (Industrial, SMF, 1510nm, 80km, LC, DOM) The Netgear CW-SFP10G80-51-I Compatible LINK-PP module is an industrial-grade 10G SFP+ CWDM optical transceiver capable of 10Gbps data transmission up to 80 kilometers over single-mode fiber (SMF).The module features a three-part internal architecture composed of a cooled EML laser transmitter, an APD photodiode integrated with a trans-impedance preamplifier (TIA), and an MCU intelligent control unit. This optimized hardware configuration ensures stable signal

Netgear CWDM-SFP-1550 Compatible LINK-PP 1.25G SFP CWDM Single Mode Optical Transceiver Module(1550nm,40km,SMF,Duplex LC,DOM) The Netgear CWDM-SFP-1550 Compatible LINK-PP module is a high performance, cost effective 1.25G SFP transceiver designed for single mode fiber networks. It supports reliable data transmission up to 40 km using a CWDM DFB laser, with built-in digital diagnostics (SFF-8472) and full compliance with SFP MSA and Class 1 laser safety standards.   Netgear Part NumberCWDM-SFP-1550Vendor NameLINK-PP Form Factor SFP Max Data Rate 1.25Gbps Wavelength 1550nm Max

NETGEAR AFM735 Compatible LINK-PP 155M SFP Specifications AFM735 functions as an industrial-grade 155M SFP multi-mode optical transceiver, pairing a 1310nm FP laser with a PIN photodetector to secure a 2km transmission span throughout a ruggedized -40°C to +85°C operating envelope. NETGEAR Part NumberAFM735Vendor NameLINK-PP Form Factor SFP Max Data Rate 155Mbps Wavelength 1310nm Max Cable Distance 2km Connector Duplex LC Media MMF Transmitter Type FP Receiver Type PIN TX Power -18 to -10dBm RX Power -30 to -6dBm

Netgear AGM732F Compatible LINK-PP 1G SFP Specifications The Netgear AGM732F Compatible LINK-PP module is a 1G SFP optical transceiver designed for stable gigabit transmission over single-mode fiber. It delivers dependable performance at a 1310nm operating wavelength with a reach of up to 10km. Netgear Part NumberAGM732FVendor NameLINK-PP Form Factor SFP Max Data Rate 1.25Gbps Wavelength 1310nm Max Cable Distance 10km Connector Duplex LC Transmitter Type FP 1310nm Media SMF Receiver Type PIN TX Power -9 to 0dBm RX Power -23 to -

Netgear AXM763-I Compatible LINK-PP 10G SFP+ Specifications Netgear AXM763-I Compatible LINK-PP module is an industrial-grade 10GBASE-LRM SFP+ optical transceiver operating at 1310nm, supporting up to 220m transmission over OM3 multi-mode fiber with a duplex LC/UPC interface and integrated DOM for real-time monitoring across MMF links. Netgear Part NumberAXM763-IVendor NameLINK-PP Form Factor SFP+ Max Data Rate 10.7Gbps Wavelength 1310nm Max Cable Distance 220m Connector Duplex LC Media MMF Transmitter Type FP Receiver Type PIN TX

Netgear DWDM-SFP10G-62.23 Compatible LINK-PP C19 10G SFP+ DWDM 100GHz Transceiver Module (SMF, 1562.23nm, 80km, Duplex LC, DOM) The Netgear DWDM-SFP10G-62.23 Compatible LINK-PP SFP+ DWDM transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 80km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP

Netgear DWDM-SFP10G-61.41-I Compatible LINK-PP 10G SFP+ Specifications The Netgear DWDM-SFP10G-61.41-I Compatible LINK-PP 10G SFP+ transceiver delivers ultra-fast data transfer rates up to 10.7Gbps over SMF, offers distances of up to 40km, and operates at an exact DWDM wavelength of 1561.41nm, ensuring dependable, long-distance connectivity with exceptional stability. Netgear Part NumberDWDM-SFP10G-61.41-IVendor NameLINK-PP Form Factor SFP+ Max Data Rate 10.7Gbps Wavelength 1561.41nm Max Cable Distance 40km Connector Duplex LC Media SMF

Netgear DWDM-SFP10G-58.98-I Compatible LINK-PP C23 10G DWDM SFP+ Transceiver Module (SMF, 1558.98nm, 40km, LC, Industrial, DOM) The Netgear DWDM-SFP10G-58.98-I Compatible LINK-PP C23 SFP+ transceiver supports up to 40km link lengths over single-mode fiber (SMF) via an LC duplex connector. This transceiver is compliant with SFF-8431 and SFF-8432 MSA standards. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is

Netgear DWDM-SFP10G-58.17 Compatible LINK-PP C24 10G SFP+ DWDM 100GHz Transceiver Module (SMF, 1558.17nm, 80km, Duplex LC, DOM) The Netgear DWDM-SFP10G-58.17 Compatible LINK-PP SFP+ DWDM transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 80km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP

Netgear DWDM-SFP10G-57.36 Compatible LINK-PP C25 10G SFP+ DWDM 100GHz Transceiver Module (SMF, 1557.36nm, 40km, Duplex LC, DOM) Netgear DWDM-SFP10G-57.36 Compatible LINK-PP SFP+ transceiver is a high-performance, cost-efficient optical module that achieves 10Gbps transmission across 40 kilometers over single-mode fiber (SMF). Its internal structure includes three core components: a cooled EML laser transmitter, a PIN photodiode combined with a trans-impedance preamplifier (TIA), and an MCU control unit. Every unit fulfills Class 1 laser safety requirements. This transceiver conforms to

Netgear DWDM-SFP10G-54.94 Compatible LINK-PP C28 10G SFP+ DWDM 100GHz Transceiver Module (SMF, 1554.94nm, 80km, Duplex LC, DOM) The Netgear DWDM-SFP10G-54.94 Compatible LINK-PP SFP+ DWDM transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 80km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP
