The HPE Aruba S1D18A Compatible LINK-PP module is a high-performance 400G QSFP-DD SR8 optical transceiver engineered for modern data center interconnects. Utilizing advanced PAM4 modulation and an 8x50G electrical interface, this 400GBASE-SR8 commercial-grade module ensures reliable multi-lane data communication. It fully complies with IEEE 802.3cd and CMIS 4.0 standards, delivering exceptional networking efficiency.
| HPE Aruba Part Number | S1D18A | Vendor Name | LINK-PP |
| Form Factor | QSFP-DD | Max Data Rate | 425Gbps |
| Connector | MPO-16/APC | Media | MMF |
| Wavelength | 850nm | Max Cable Distance | 70m@OM3/100m@OM4 |
| Transmitter Type | VCSEL | Receiver Type | PIN |
| Modulation (Electrical) | 8x50G-PAM4 | Modulation (Optical) | 8x50G-PAM4 |
| DSP | TX and RX | Inbuilt FEC | No |
| DDM/DOM | Supported | Operating Temperature range | 0°C to +70°C |
| Protocols | QSFP-DD MSA, CMIS 4.0, IEEE 802.3cd | Warranty | 5 Years |
The HPE Aruba S1D18A Compatible LINK-PP delivers outstanding efficiency with a maximum power consumption of under eight watts. This hot-pluggable 400G QSFP-DD module integrates a highly reliable VCSEL array and PIN PD array. Operating smoothly on a single 3.3V power supply, it guarantees superior thermal performance and stable signal integrity.
This eight-channel pluggable parallel fiber-optic transceiver provides robust 400G connections. The S1D18A utilizes cutting-edge optical components to facilitate rapid data transfer, making it an indispensable asset for upgrading high-density enterprise networks and scaling cloud infrastructures.
Designed for demanding artificial intelligence workloads and cloud networks, the S1D18A guarantees massive bandwidth capabilities. This 400G QSFP-DD transceiver accelerates machine learning data processing and fulfills stringent 400GE interconnect requirements across next-generation AI data centers.
Operating at a nominal 850nm wavelength, the S1D18A is optimized for short-range multimode fiber systems. Its integrated 850nm VCSEL technology ensures precise optical transmission, minimizing signal degradation while maintaining excellent spectral efficiency across all data lanes.
This 400GBASE-SR8 module achieves impressive reach for internal data center routing. The S1D18A supports transmission distances up to 70 meters over OM3 multimode fiber and reaches up to 100 meters using OM4 fiber with Forward Error Correction.
Equipped with a single-row MPO-16/APC optical connector, the S1D18A ensures low insertion loss and high optical return loss tolerance. This standardized physical interface facilitates seamless patch panel integration and simplifies high-density fiber cabling deployments.
Featuring integrated Digital Optical Monitoring, the S1D18A allows network administrators to continuously track critical parameters. This DOM functionality monitors operating temperature, voltage, and optical power in real-time, significantly improving fault isolation and overall network reliability.
Compatibility tested in the LINK-PP lab. View test report
The HPE Aruba S1D18A Compatible LINK-PP complies with rigorous international regulatory standards. These 400G QSFP-DD modules guarantee safe, environmentally friendly, and legally compliant operation across diverse global enterprise networks.
Every S1D18A undergoes a comprehensive quality testing program before deployment. This meticulous evaluation process ensures consistent performance, maximum durability, and fault-free operation in high-stress data environments.
Demonstrating exceptional manufacturing standards, the S1D18A holds CE, FCC, UKCA, UL, and REACH certifications. Furthermore, this optical transceiver is fully compliant with RoHS 2.0 environmental regulations.
Validated through extensive compatibility protocols, the S1D18A integrates effortlessly with major network switches and routers. This certified interoperability ensures seamless plug-and-play functionality without vendor lock-in issues.
Advanced laboratory examinations validate the exceptional stability of our 400G QSFP-DD optical transceivers, confirming their readiness for mission-critical enterprise communication networks.
Verifies the 850nm center wavelength and spectral width to guarantee precise optical signal transmission.
Analyzes PAM4 modulation signal integrity to ensure optimal clarity and minimize transmission distortion risks.
Confirms ultra-low bit error rates to ensure flawless data integrity across 400G high-speed connections.
Validates reliable transceiver operation across standard commercial case temperatures ranging from 0 to 70°C.
We implement strict logistics protocols to ensure your 400G QSFP-DD optical transceivers arrive in pristine condition, ready for immediate data center installation.
Each transceiver is sealed in premium electrostatic discharge protective packaging bags.
Custom-molded foam inserts prevent mechanical damage during rigorous global transit conditions.
Streamlined inventory management guarantees rapid order fulfillment and priority dispatching services.
Trusted international courier partnerships ensure highly secure and trackable worldwide shipping.
Installing the S1D18A is extremely straightforward. Simply slide the hot-pluggable QSFP-DD transceiver into your network switch port until secured, then connect your MPO-16 patch cable to create a reliable 400G high-bandwidth link for immediate enterprise deployment.
LINK-PP provides professional technical support, including pre-sales consultation, compatibility verification, and post-deployment troubleshooting to ensure smooth network operation.
Professional technical guidance to help customers select the most suitable S1D18A modules based on network architecture and application requirements.
Compatibility checks and validation to ensure seamless operation with Cisco switches and other supported networking platforms.
Step-by-step support for installation, configuration, and initial deployment to ensure stable and correct operation.
Ongoing technical support throughout the product lifecycle to ensure reliable performance in enterprise and carrier-grade networks.
LINK-PP provides after-sales support for the smooth deployment and reliable operation of the optical modules.
15-day no-reason return and refund
Free replacement for dead-on-arrival (DOA) or defective items within the initial period
Free repair services for manufacturing defects throughout the warranty period
Warranty exclusions and conditions apply
