LPJ2011KONL 100 base-t rj45 jack with transformer tab up orange&green yellow leds

LPJ2011KONL 100 Base-T RJ45 Jack with Transformer Tab Up Orange&Green/Yellow Leds

Product summary

Product
LPJ2011KONL 100 Base-T RJ45 Jack with Transformer Tab Up Orange&Green/Yellow Leds
SKU
172281
P/N
LPJ2011KONL
Price
$ 3.18
Stock
1300 in Stock
Sold
65.6K
Unit price $ 3.18
New Users: $ 10.00 Coupon on Your First Order
Code linkpp2610
For Order Over $ 1,000.00 Get $ 15.00 Off
Code Linkpp15
For Order Over $ 3,000.00 Get $ 50.00 Off
Code Linkpp50
For Order Over $ 5,000.00 Get $ 100.00 Off
Code Linkpp100
Manufacture: LINK-PPP/N: LPJ2011KONLSKU: 172281

LINK-PP originalDatasheet3D ModelAll downloads

Compatible P/N:
LPJ2011KONL
Volume pricing Online tiers · larger qty or custom price on request
$ 3.180
1–99 pcs
$ 2.604
100–599 pcs
$ 2.286
600–1,199 pcs
$ 1.746
1,200–5,999 pcs
$ 1.492
≥6,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:
1300 in Stock
Shipping:
$ 29.47
to United States via FedEx IP
Estimated delivery time : 3 - 6 days.
5-Year Warranty 15-Day Returns 15-Day Exchange
Warranty
  • Providing industry-leading 5-year warranty.
  • Read the table for details of all products' warranty.
Returns & Exchange
  • Refunds will be received about 5 business days after the receipt of returned items.
  • Items in stock for replacement can be shipped within 1 business day.
  • Read the full return policy for details.
Free shipping over $ 600.00.
Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).
Quantity:
SPQ 50
Total Price:
$ 3.18
Packaging Details
50 pcs
1200 pcs
Tray
40×32×33 cm
0.01 kg
12.3 kg

LINK-PP LPJ2011KONL 10/100 Base-T Industrial RJ45 Jack with Transformer for Digital Camera and Smart Meters (Single Port, Tab Up, Orange&Green/Yellow Led)


The LPJ2011KONL supports speed 10/100 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as The Handheld Device, Game Controller, Patient Care and Game Controller.


LINK-PP Part Number:
LPJ2011KONL Connector Type
Jack
Part Status
Active Mounting Type
Through Hole
Number of Positions/Contacts
6p8c (RJ45, Ethernet) Application-Lan
Ethernet(NoN PoE)
Number of Ports
1x1 PortSpeed
10/100 Base-T
Latch
UPCores per Port
4
Orientation
90° Angle (Right)PCB Mount Angle

SIDE ENTRY

Shield EMI Tabs
WithLED Option

Orange&Green/Yellow Leds

PCB
FR4PCB Retaining Post

T POST

Package Height (Inches/mm)
0.522/13.25Package Length (Inches/mm)

1.08/25.60

Package Width (Inches)
0.661/16.80Temperature

0℃ TO 70℃

Bst Circuit
YesAutomDX

YES

Diodes
NoContact Mating Area Plating

GOLD 6u"/15u"/30u"

Turns Ratio RX/TX
1CT:1CTConfiguration RX/TX

T,C

LINK-PP

Matching Products

Pictures ID# Description Price Stock Add to Cart

Download

LPJ2011KONL Drawing LPJ2011KONL.pdf

Questions & Answers

No questions yet

Be the first to ask about specs, compatibility, or lead time.

Ask a Question
  • A:
    No, it is a hundred megabit part and the integrated magnetics are specified for that rate, so a gigabit PHY will not get the performance its datasheet promises. We matched the jack to a fast Ethernet PHY and set the port speed accordingly in firmware, then verified the link on a long lead. If the product later needs a thousand megabit variant, that is a different magnetics set and a different connector. Labelling the two clearly on the board prevents mix ups in the field. by LINK-PP Technical Support
  • A:
    Because the release is on top, anything mounted directly above the opening will get in the way of a finger or a cable boot. We reserved a clear strip on the panel for this port and dry fitted a patch lead with the board seated in its guides. Where a display already occupies that zone, a lower latch version is the better fit. Take the keep out from the mechanical drawing instead of guessing from the plastic body. by LINK-PP Technical Support
  • A:
    Two pairs carry the traffic and the transformer sits inside the housing, so keep those runs short between the jack and the PHY and give them a continuous reference plane. We placed the connector first from the chassis drawing, then worked backwards with the termination parts, which avoided pushing a tall component into the high speed area. Check the centre tap and Bob Smith network against the schematic at bring up. A long cable test tells you more than a short one here. by LINK-PP Technical Support
  • A:
    The two windows use an orange emitter alongside a green yellow one, which is a less common palette than the usual green yellow pair and makes the port easy to pick out on a crowded face. Colour alone does not define the function, so the assignment lives in firmware and is repeated on the front legend. We checked drive polarity on the first article with a live cable at a hundred megabits. If a family needs a different palette, specify it at the jack level. by LINK-PP Technical Support
