LP72423ANL 10g base-t single port smd magnetic transformer modules 24 pin

LINK-PP LP72423ANL 10G Base-T Single Port SMD Magnetic Transformer Modules 24 PIN

Product summary

Product
LINK-PP LP72423ANL 10G Base-T Single Port SMD Magnetic Transformer Modules 24 PIN
SKU
161642
P/N
LP72423ANL
Price
$ 3.10
Stock
1050 in Stock
Sold
92.6K
Unit price $ 3.10
New Users: $ 10.00 Coupon on Your First Order
Code linkpp2610
For Order Over $ 1,000.00 Get $ 15.00 Off
Code Linkpp15
For Order Over $ 3,000.00 Get $ 50.00 Off
Code Linkpp50
For Order Over $ 5,000.00 Get $ 100.00 Off
Code Linkpp100
P/N: LP72423ANLSKU: 161642

LINK-PP originalDatasheet3D ModelAll downloads

Compatible:
LINK-PP
Compatible P/N:
LP72423ANL
Volume pricing Online tiers · larger qty or custom price on request
$ 3.100
1–9 pcs
$ 3.100
10–999 pcs
$ 2.046
1,000–5,999 pcs
$ 1.643
6,000–11,999 pcs
$ 1.488
12,000–23,999 pcs
$ 1.333
≥24,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:
1050 in Stock
Shipping:
$ 29.47
to United States via FedEx IP
Estimated delivery time : 3 - 6 days.
5-Year Warranty 15-Day Returns 15-Day Exchange
Warranty
  • Providing industry-leading 5-year warranty.
  • Read the table for details of all products' warranty.
Returns & Exchange
  • Refunds will be received about 5 business days after the receipt of returned items.
  • Items in stock for replacement can be shipped within 1 business day.
  • Read the full return policy for details.
Free shipping over $ 600.00.
Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).
Quantity:
Total Price:
$ 3.10

LINK-PP LP72423ANL 10G Base-T Magnetic Transformer Modules For Digital Camera (SMD,24PIN,Single Port )

The LP72423ANL speed 10G Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to Router, Set-top Box, SMPS, Digital Camera.

LINK-PP Part Number LP72423ANL Transformer Type Lan Transformer
Part Status Active Turns Ratio - Primary:Secondary 1:1 Transmitter, 1:1 Receiver
Construction OPEN FRAME Application-Lan Ethernet(NON PoE)
Number of Ports SINGLE Speed 10G Base-T
Package Tape & Reel Cores per Port 8
AutomDX Yes Comment

SAME AS NL VERSION

PIN number 24 Mounting Type

Surface Mount

Package Height (Inches/mm) 0.244/6.20 Package Length (Inches/mm) 0.715/18.15
Package Width (Inches/mm) 0.630/16.00 Temperature -40℃ TO +85℃
Turns Ratio RX/TX 1CT:1CT Configuration RX/TX T,C,S

LINK-PP
