LPJ0011HDNL 10 100 base-t integrated magnetics modular jack rj45 connector

LPJ0011HDNL 10/100 Base-T Integrated Magnetics Modular Jack RJ45 Connector

Product summary

Product
LPJ0011HDNL 10/100 Base-T Integrated Magnetics Modular Jack RJ45 Connector
SKU
103900
P/N
LPJ0011HDNL
Price
$ 2.08
Stock
9990 in Stock
Sold
588
Unit price $ 2.08
New Users: $ 10.00 Coupon on Your First Order
Code linkpp2610
For Order Over $ 1,000.00 Get $ 15.00 Off
Code Linkpp15
For Order Over $ 3,000.00 Get $ 50.00 Off
Code Linkpp50
For Order Over $ 5,000.00 Get $ 100.00 Off
Code Linkpp100
P/N: LPJ0011HDNLSKU: 103900

LINK-PP originalDatasheet3D ModelAll downloads

Compatible:
LINK-PP
Compatible P/N:
LPJ0011HDNL
Volume pricing Online tiers · larger qty or custom price on request
$ 2.080
1–99 pcs
$ 1.706
100–599 pcs
$ 1.498
600–1,199 pcs
$ 1.145
1,200–5,999 pcs
$ 0.978
≥6,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:
9990 in Stock
Shipping:
$ 29.47
to United States via FedEx IP
Estimated delivery time : 3 - 6 days.
5-Year Warranty 15-Day Returns 15-Day Exchange
Warranty
  • Providing industry-leading 5-year warranty.
  • Read the table for details of all products' warranty.
Returns & Exchange
  • Refunds will be received about 5 business days after the receipt of returned items.
  • Items in stock for replacement can be shipped within 1 business day.
  • Read the full return policy for details.
Free shipping over $ 600.00.
Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).
Quantity:
SPQ 50
Total Price:
$ 2.08
Packaging Details
50 pcs
1200 pcs
Tray
32×30×31 cm
0.007 kg
8.5 kg

Single Port RJ45 Female Connector with 10/100 Base-T Integrated Magnetics, Yellow/Green LED, Tab Down, RoHS

LINK-PP Part Number:
LPJ0011HDNLConnector Type
Jack
Part Status
Active Mounting Type
Through Hole
Number of Positions/Contacts
8p8c (RJ45, Ethernet) Application-Lan
Ethernet(NoN PoE)
Number of Ports
1x1 PortSpeed
10/100 Base-T
Latch
Down Cores per Port
4
Orientation
90° Angle (Right)PCB Mount Angle

SIDE ENTRY

Shield EMI Tabs
WithoutLED Option

Yellow/Green

PCB
FR4PCB Retaining Post

T POST

Package Height (Inches/mm)
0.524/13.30Package Length (Inches/mm)

0.837/21.25

Package Width (Inches/mm)
0.627/15.93Temperature

0℃ TO 70℃

Bst Circuit
YesAutomDX

YES

Diodes
NoContact Mating Area Plating

GOLD 6u"/15u"/30u"

Turns Ratio RX/TX
1CT:1CTConfiguration RX/TX

T,C

LINK-PP

Matching Products

Pictures ID# Description Price Stock Add to Cart

Download

Product Drawing LPJ0011HDNL-Drawing.pdf

Questions & Answers

No questions yet

Be the first to ask about specs, compatibility, or lead time.

Ask a Question
  • A:
    Two signal pairs pass through the internal windings of this jack. Each pair keeps a separate coil and tail set. The centre tap on a winding feeds the line side only. Your PHY assigns which pair sends and which receives. by LINK-PP Technical Support
  • A:
    The coils and their taps are built into the shell of this jack. The Bst capacitors and terminators sit on the board nearby. No such piece is sealed in the connector body. Your schematic places those parts and their nets. by LINK-PP Technical Support
  • A:
    Both windings are wound 1:1 on this part for each pair. The ratio holds on the two 10/100 lines alike. Each centre tap lands midway on its line side coil. Your schematic decides how you bias that tap. by LINK-PP Technical Support
  • A:
    Both signal pairs get isolation coils built into this 1x1 shell. The 8 contacts run through those coils before the board tails. The Bst parts also terminate within the shell. Your board drops the separate transformer for that link. by LINK-PP Technical Support

Customer Reviews

  • 5

    99 Reviews

  • 5 Stars
    98%
    4 Stars
    2%
    3 Stars
    0%
    2 Stars
    0%
    1 Star
    0%
  • All Reviews (99)
No data
H***n
Verified Purchase
5.0
2026-11-14
Tabs would have given us a second bond path. It went in without touching the neighbour, no fuss.
D***u
Verified Purchase
5.0
2026-04-08
Same height as before. It is within spec against the old part.
Z***t
Egypt
Verified Purchase
5.0
2025-11-23
The bare shell is why this part number is on our plate. Our bracket carries the ground already, and a shell with tabs would have put two bonds on the same bracket. This one leaves the bond to the plate, the eight contacts landed first plug, and the height matched the cutout, good.
M***r
Verified Purchase
5.0
2025-06-07
Eight contacts and four cores, two pairs. No surprises on the turns ratio.
J***t
Verified Purchase
4.0
2024-10-23
Two cartons came with dented corners, but the shells were all square. Eight contacts and both pairs landed first plug, and the plate closed over the bare body. No drama unpacking it on the line.
