LINK-PP Cage LP11DC01000E QSFP+ 1x1 avec ressorts EMI et doigts LINK-PP Part Number LP11DC01000E Part Status Active Connector Style Cage Connector Type QSFP Port Matrix Configuration 1x1 Ports Mounting Type Through Hole, Right Angle Termination Press-Fit Features EMI Shielded Cage Material COPPER ALLOY EMI Containment Feature Type Internal/External EMI Springs  Length (Inches/mm)  2.315/58.80 Width (Inches/mm)  0.738/18.75 Height (Inches/mm)  0.384/9.75 Operating Temperature Range -

1888971-2,QSFP+ ,Cage Assembly, 1 x 1, Internal/External EMI Springs, Included Lightpipe, Standard, Data Rate (Max) 14 Gb/s, 1 Port Part Number 1888971-2 Part Status Active Connector Style Cage with Heat Sink Connector Type QSFP+ Data Rate (Max)(Gb/s) 14 Mounting Type Through Hole, Right Angle Termination Press-Fit Features EMI Shielded Port Matrix Configuration 1x1 Ports Number of Ports 1 Number of Rear EONs per Port Column 2 Connector Mounting Type Board Mount Heat Sink Style Pin Heat Sink Height 13.5mm[.531in] Operating

LINK-PP LPSFP3802 QSFP+ 1x1 Cage Connector Press-Fit Through Hole LINK-PP Part Number LPSFP3802 Part Status Active Connector Style Cage Connector Type QSFP+ Number of Ports 1x1 Port Mounting Type - CONTACT AREA GOLD PLATING OVER 50u"MIN. NICKLE HOUSING THERMOPLASTIC GLASS FILLED Operating Temperature Range -40 – 85°C

QSFP+ , Cage Assembly, 1 x 1, Internal/External EMI Springs, Standard, Data Rate (Max) 14 Gb/s, 1 Port, Pin Part Number 1888631-3 Part Status Active Connector Style Cage with Heat Sink Connector Type QSFP+ Data Rate (Max)(Gb/s) 14 Mounting Type Through Hole, Right Angle Termination Press-Fit Features EMI Shielded Port Matrix Configuration 1x1 Ports Number of Ports 1 Number of Rear EONs per Port Column 2 Connector Mounting Type Board Mount Operating Temperature Range -55 – 105°C Pluggable I/O Applications SFP+ Stacked

zQSFP+,Cage, 1 x 3, Customer Applied Gasket, Standard, 3 Port, 1 Rear EONs per Port Column, Cable-to-Board, Sealable Part Number: 2007473-1 Part Status Active Connector Style Cage, Ganged (1 x 3) Connector Type QSFP+ Number of Positions - Mounting Type Through Hole, Right Angle Termination Press-Fit Features EMI Shielded Port Matrix Configuration 1x3 Ports Number of Ports 1 Number of Rear EONs per Port Column 1 Data Rate (Max)(Gb/s) - Operating Temperature Range - Pluggable I/O Applications SFP+ Stacked Belly-to-Belly Circuit

QSFP+ , Cage Assembly, 1 x 1, Internal/External EMI Springs, Standard, Data Rate (Max) 14 Gb/s, 1 Port, Pin Part Number 1888631-2 Part Status Active Connector Style Cage with Heat Sink Connector Type QSFP+ Data Rate (Max)(Gb/s) 14 Mounting Type Through Hole, Right Angle Termination Press-Fit Features EMI Shielded Port Matrix Configuration 1x1 Ports Number of Ports 1 Number of Rear EONs per Port Column 2 Connector Mounting Type Board Mount Operating Temperature Range -55 – 105°C Pluggable I/O Applications SFP+ Stacked

QSFP+ , Cage, 1 x 1, Internal/External EMI Springs, Standard, 1 Port, 2 Rear EONs per Port Column, Cable-to-Board Part Number 1888617-1 Part Status Active Connector Style Cage Connector Type QSFP+ Number of Positions - Mounting Type Through Hole, Right Angle Termination Press-Fit Features EMI Shielded Port Matrix Configuration 1x1 Ports Number of Ports 1 Data Rate (Max)(Gb/s) - Connector Mounting Type Board Mount Operating Temperature Range - Pluggable I/O Applications SFP+ Stacked Belly-to-Belly Circuit Application Signal

QSFP+ , Cage Assembly, 1x4, Customer Applied Gasket, Standard, Data Rate (Max) 14 Gb/s, 4 Port, Pin Part Number 2007625-1 Part Status Active Connector Style Cage, Ganged (1 x 4) with Heat Sink Connector Type QSFP+ Heat Sink Height 4.2mm[.165in] Mounting Type Through Hole, Right Angle Termination Press-Fit Features EMI Shielded Port Matrix Configuration 1x4 Ports Number of Ports 4 Number of Rear EONs per Port Column 1 Data Rate (Max)(Gb/s) 14 Operating Temperature Range -55 – 105°C Pluggable I/O Applications SFP+

2085945-6,QSFP+ , Cage Assembly with Integrated Connector, 2 x 1, Elastomeric Gasket, Included Lightpipe, Standard Part Number:  2085945-6 Part Status Active Connector Style Receptacle with Cage, Ganged (2x1) Connector Type QSFP+ Number of Positions 76 (38 x 2) Mounting Type Through Hole, Right Angle Termination Press-Fit Features EMI Shielded Port Matrix Configuration 2x1 Ports Number of Ports 2 Number of Rear EONs per Port Column 0 Data Rate (Max)(Gb/s) 14 Operating Temperature Range -55 – 105°C Pluggable I/O

QSFP+ , Cage Assembly, 1 x 4, Elastomeric Gasket, Standard, Data Rate (Max) 14 Gb/s, 4 Port Part Number 2170287-1 Part Status Active Connector Style Cage, Ganged (1 x 4) with Heat Sink Connector Type QSFP+ Heat Sink Height 4.2mm[.165in] Mounting Type Through Hole, Right Angle Termination Press-Fit Features EMI Shielded Port Matrix Configuration 1x4 Ports Number of Ports 4 Number of Rear EONs per Port Column 2 Data Rate (Max)(Gb/s) 14 Operating Temperature Range -55 – 105°C Pluggable I/O Applications SFP+ Stacked

Spécifications de la cage TE 2170290-3 QSFP+ 1x4 LINK-PP Référence LPXXXXXXXX TE Référence 2170290-3 E/S enfichables Type de produit : Cage Type de connecteur : QSFP+ Configuration de la matrice de ports : 1x4 Nombre de ports : 4 Type d'accessoire thermique : Dissipateur thermique inclus Type de cage : Assemblée Scellable : Oui Application du circuit : Signal Plage de température de fonctionnement : -55 – 105 °C Indice d'inflammabilité UL : UL 94V-0 Méthode de terminaison sur circuit imprimé : Traversant - Enclenchement par pression Applications d'E/S enfichables : SFP+ Empilé (face à face) Guides de lumière inclus : Non

Spécifications de la cage QSFP+ TE 2170539-3 LINK-PP Part Number LPXXXXXXXX TE Part Number 2170539-3 Pluggable I/O Product Type Cage Assembly Connector Type QSFP+ Port Matrix Configuration 1x1 Port Number of Ports 1 Thermal Accessory Type Included Heat Sink Cage Type Single Sealable Yes Circuit Application Signal Operating Temperature Range -55 – 105 °C Heat Sink Height 7.4m [ .291in ] Included Lightpipes Yes EMI Containment Feature Type Internal/External EMI Springs

Spécifications de la cage TE 2287652-1 QSFP+ 1X1 LINK-PP Part Number LPXXXXXXXX TE Part Number 2287652-1 Pluggable I/O Product Type Cage Assembly Connector Type QSFP+ Port Matrix Configuration 1x1 Port Number of Ports 1 Thermal Accessory Type Included Heat Sink Cage Type Ganged Sealable No Circuit Application Signal Operating Temperature Range -55 – 105 °C [ -67 – 221 °F ] UL Flammability Rating UL 94V-0 Included Lightpipes No EMI Containment Feature Type Internal/External EMI Springs Termination Method to PCB

Spécifications de la cage TE 2293961-5 QSFP+ 2x2 LINK-PP Référence LPXXXXXXXX TE Référence 2293961-5 E/S enfichables Type de produit : Boîtier avec connecteur intégré Type de connecteur : QSFP+ Étanchéité : Non Type de boîtier : Empilé Configuration de la matrice de ports : 2x2 Nombre de ports : 4 Nombre de positions : 152 Débit de données (max.) (Gb/s) : 10 Plage de température de fonctionnement : -55 – 105 °C Application du circuit : Signal Inclus : Guides de lumière : Oui Type de protection contre les interférences électromagnétiques : Ressorts internes/externes

Spécifications de la cage TE 2298896-8 QSFP+ 2x1 LINK-PP Part Number LPXXXXXXXX TE Part Number 2298896-8 Pluggable I/O Product Type Cage Assembly with Integrated Connector Connector Type QSFP+ Sealable No Cage Type Stacked Port Matrix Configuration 2x1 Port Number of Ports 2 Data Rate (Max) (Gb/s) 10 Contact Current Rating (Max) (A) .5 Operating Temperature Range -55 – 105°C  Circuit Application Signal Included Lightpipes Yes EMI Containment Feature Type Internal/External EMI Springs

Spécifications de la cage TE 2110819-1 QSFP+ 1X1 LINK-PP Part Number LPXXXXXXXX TE Part Number 2110819-1 Pluggable I/O Product Type Cage Assembly Connector Type QSFP+ Port Matrix Configuration 1x1 Port Number of Ports 1 Data Rate (Max) (Gb/s) 14 Sealable No Operating Temperature Range -55 – 105 °C Circuit Application Signal
