Specifications of LINK-PP 1.25G BiDi 1x9 Transceiver
The LINK-PP L9-SC31551G-20PPI5 is a high-performance 1.25G BiDi 1x9 optical transceiver engineered for robust industrial applications. It features a 5V power supply, FP laser, and PIN detector, operating across extreme temperatures from -40°C to +85°C. Utilizing a PECL data interface, this module guarantees stable signal transmission for demanding fiber optic links.
LINK-PP Part Number
L9-SC31551G-20PPI5
Vendor Name
LINK-PP
Form Factor
1x9
Max Data Rate
1.25Gbps
Wavelength
1310nm-TX/1550nm-RX
Max Cable Distance
20km
Fiber Interface
Simplex SC
Fiber Type
SMF
Transmitter Type
FP
Receiver Type
PIN
Differential Input/ Output
PECL
Signal Detect
PECL
Power Supply
5V
Operating Temperature Range
-40 to +85℃
Key Features of LINK-PP L9-SC31551G-20PPI5
This industrial-grade transceiver delivers exceptional reliability with its 5V power requirement and wide operating temperature range. The L9-SC31551G-20PPI5 supports a 20km transmission distance and utilizes advanced WDM technology, making it an ideal optical module for gigabit ethernet and continuous digital video transmission.
Standard 1x9 Package for Reliable PCB Mounting
Featuring an industry-standard 9-pin through-hole footprint, the L9-SC31551G-20PPI5 ensures secure and reliable PCB mounting. This classic 1x9 package design offers excellent mechanical stability, preventing connection drops in high-vibration environments commonly found in industrial networking equipment.
1.25G Single-Fiber Connectivity for Industrial Control Systems
Operating at a fast 1.25Gbps data rate, this single-fiber optical module provides high-speed connectivity crucial for modern industrial control systems. The L9-SC31551G-20PPI5 effectively minimizes fiber cabling costs while maximizing network throughput and operational efficiency.
WDM Technology: 1310nm-TX/1550nm-RX Bi-Directional Link
Built with advanced Wavelength Division Multiplexing (WDM) technology, the L9-SC31551G-20PPI5 transmits at 1310nm via an FP laser and receives at 1550nm using a PIN detector, enabling efficient, full-duplex bi-directional communication over a single strand of fiber.
Stable 20km Transmission for Medium-Reach Networks
Designed for medium-reach optical networks, this 1.25G BiDi transceiver guarantees stable data delivery up to 20 kilometers over 9/125μm single-mode fiber. It is perfectly suited for extending campus networks, factory automation links, and integrated security systems.
Simplex SC Interface with Low EMI Design
The L9-SC31551G-20PPI5 incorporates a robust Simplex SC optical interface, allowing for quick, snap-in fiber connections. Its optimized internal shielding ensures a low EMI design, complying with rigorous electromagnetic interference standards to maintain crystal-clear signal integrity.
The LINK-PP L9-SC31551G-20PPI5 1.25G 1x9 transceiver is fully certified to meet global industry standards, guaranteeing unmatched safety, environmental compliance, and long-term operational reliability for enterprise applications.
Every L9-SC31551G-20PPI5 undergoes a comprehensive quality control program. Our advanced factory screening includes rigorous physical and optical assessments to ensure maximum durability before leaving the production line.
This optical module proudly holds CE, FCC, UKCA, UL, and REACH certifications. It features exceptional EMI suppression and meets strict Class 1 ESD electrostatic discharge immunity requirements.
This product is in conformity with ISO9001. This system is valid to a company engaging in development, production and supply service of fiber optical products. Please contact us to learn more.
ISO/IEC 27001 is an international standard for managing and processing information security. This standard is jointly developed by the International Organization for Standardization (ISO) and the International Electrotechnical Commission (IEC). It sets out requirements for establishing, implementing, maintaining, and continually improving an information security management system (ISMS). Ensuring the confidentiality, integrity, and availability of organizational information assets, obtaining an ISO 27001 certificate means that the enterprise has passed the audit conducted by a certification body, proving that its information security management system has met the requirements of the international standard. Please contact us to learn more.
This product is in conformity with ISO14001.It is intended for use by an organization seeking to manage its environmental responsibilities in a systematic manner that contributes to the environmental pillar of sustainability. Please contact us to learn more.
ISO 45001 is a global standard that sets out the requirements for an occupational health and safety management system (OH&SMS).
REACH is a European Union regulation concerning the Registration, Evaluation, Authorization and Restriction of Chemicals. It came into force on 1st June 2007 and replaced a number of European Directives and Regulations with a single system. The regulation aims to protect human health and environmental safety, maintain and improve the competitiveness of the EU chemical industry, and develop innovative capabilities for non-toxic and harmless compounds to prevent market fragmentation, increase the transparency of the use of chemicals, promote non-animal experiments, and pursue sustainable social development.Please contact us to learn more.
This product meets the applicable requirements of Directive (EU) 2015/863 of RoHS. It restricts the use of 10 hazardous materials in the manufacture of various types of electronic and electrical equipment: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls, polybrominated diphenyl ethers, and four different phthalates. Please contact us to learn more.
This product fully accords with the FCC, which aims to manage the radio wave and magnetic fields more reasonably. Please contact us to learn more.
CB is an international system operated by IECEE. This product is based on IEC standards for testing the safety performance of electrical products. Please contact us to learn more.
This product fully accords with UKCA (UK Conformity Assessed) certificate, which signifies that it meets all relevant quality standards as well as health and safety requirements. Please contact us to learn more.
UL certification is a non-mandatory certification in the United States,mainly testing and certification of product safety performance.Its ultimate purpose is to obtain products with a fairly safe level for the market,and to contribute to ensuring human health and property safety.Please contact us to learn more.
Certified for Seamless PCB Integration & Protocol Compatibility
Fully compliant with the ITU-T G.957 standard, the L9-SC31551G-20PPI5 guarantees seamless protocol compatibility and effortless PCB integration for Gigabit Ethernet and complex fiber channel routing infrastructure.
Rigorous Testing Ensures Reliable 1x9 Performance
To validate its industrial-grade capabilities, the L9-SC31551G-20PPI5 is subjected to a series of intensive electro-optical tests, ensuring flawless functionality in extreme conditions.
Optical Spectrum Test
Evaluates the FP laser's 1310nm wavelength accuracy and output spectrum width consistency.
Eye Pattern Test
Verifies the optical waveform against ITU-T standards for optimal signal integrity and low jitter.
Bit Error Rate Test
Confirms zero packet loss and a flawless 1.25Gbps data transmission rate over 20km.
Temperature Test
Guarantees continuous, stable operation across extreme industrial temperatures ranging from -40°C to +85°C.
Product Shipping for LINK-PP L9-SC31551G-20PPI5 1.25G 1x9
We provide secure, globally optimized shipping solutions for the L9-SC31551G-20PPI5, ensuring your industrial optical transceivers arrive in pristine condition and completely on schedule.
Anti-Static Protective Packaging
Each transceiver is sealed in premium ESD-safe bags to prevent electrostatic damage.
Shock-Resistant Transport Protection
Enclosed in custom-fitted, shock-absorbing materials to withstand impacts during transit.
Fast Order Processing and Dispatch
Orders are verified and dispatched rapidly to minimize your project lead times.
Global Logistics and International Delivery
Partnered with trusted international couriers for reliable worldwide shipping and customs clearance.
To install the LINK-PP L9-SC31551G-20PPI5 1.25G 1x9 transceiver, directly solder the 9-pin module onto your PCB layout. Apply a stable 5V power supply, then plug a single-mode fiber into the Simplex SC interface to establish the bi-directional optical link.
L9-SC31551G-20PPI5 Technical Support
LINK-PP provides professional technical support, including pre-sales consultation, compatibility verification, and post-deployment troubleshooting to ensure smooth network operation.
Pre-Sales Technical Consultation
Professional technical guidance to help customers select the most suitable L9-SC31551G-20PPI5 modules based on network architecture and application requirements.
Compatibility Verification Support
Compatibility checks and validation to ensure seamless operation with Cisco switches and other supported networking platforms.
Deployment & Installation Assistance
Step-by-step support for installation, configuration, and initial deployment to ensure stable and correct operation.
Long-Term Technical Assurance
Ongoing technical support throughout the product lifecycle to ensure reliable performance in enterprise and carrier-grade networks.
