Our switch is installed in a factory cabinet, and the internal temperature is usually around 55°C. Can we use this model?

The module can operate up to 70°C case temperature, but we recommend checking the actual module case temperature and ensuring sufficient ventilation in the cabinet.

We need remote monitoring because the fiber link is difficult to access. Does this module provide optical diagnostics?

Yes. It supports real-time DDM monitoring under SFF-8472, allowing compatible equipment to read information such as optical transmit power, receive power, temperature, voltage, and bias current.

We are replacing an old 1G CWDM optical transceiver in a storage network. Does this SFP transceiver support 1G Fibre Channel?

Yes. This LS-CW591G-80C SFP optical transceiver supports 1.063Gbps Fibre Channel, making it suitable for many 1G SAN and storage connectivity applications.

We have a 75km single-mode fiber route with several patch panels in between. Is this 80km CWDM SFP suitable?

It may be suitable, as this module supports transmission distances of up to 80km over single-mode fiber. However, 75km is close to the maximum distance, so the total link loss should be checked carefully. Please include fiber attenuation, connector and patch-panel loss, splice loss, and CWDM MUX/DEMUX insertion loss.

We are expanding our 1G CWDM network and already have a MUX/DEMUX with an available 1590nm port. Can this SFP be used on that channel for a long-distance single-mode fiber link?

Yes. The LS-CW591G-80C is a 1G CWDM SFP operating at 1590nm, so it can be installed in a matching 1590nm channel on a CWDM MUX/DEMUX. It is designed for duplex single-mode fiber links and supports transmission distances of up to 80km.

Breadcrumb: Home; Products; Optics Transceivers | SFP Modules; 1/2/4G Transceiver Modules; 1G CWDM/DWDM SFP; 203426

Click to open expanded view

LINK-PP LS-CW591G-80C 1G SFP CWDM 1590nm 80km Duplex LC DDM SMF Optical Transceiver Module

Name: LINK-PP LS-CW591G-80C 1G SFP CWDM 1590nm 80km Duplex LC DDM SMF Optical Transceiver Module
Brand: LINK-PP
SKU: 203426
Price: 44.72 USD
Availability: InStock
Rating: 4.9 (23 reviews)

# 203426

Product: LINK-PP LS-CW591G-80C 1G SFP CWDM 1590nm 80km Duplex LC DDM SMF Optical Transceiver Module
SKU: 203426
P/N: LS-CW591G-80C
Price: $ 52
Stock: 75 in Stock
Sold: 425
Product URL: https://www.l-p.com/products/492892.htm

For Order Over $1000 Get $15.00 Off , Code: Linkpp15

For Order Over $3000 Get $50.00 Off , Code: Linkpp50

For Order Over $5000 Get $100.00 Off , Code: Linkpp100

New Users: $10 Coupon for Orders , Code: linkpp2610

23 Reviews

5 Questions

Request Stock

425 Sold

$ 52

Free shipping over $600, If you need a more favorable price, please contact us directly.

Qty (pcs) :

Unit Price :

$ 52

100

$ 49.4

1000

$ 47.84

3000

$ 46.28

6000

$ 44.72

Manufacture: LINK-PP

P/N: LS-CW591G-80C

Compatible:: Cisco; LINK-PP; Allied Telesis; Arista; Brocade; Ciena; Dell; Extreme; Juniper; Netgear

Wavelength:: 1270nm; 1290nm; 1310nm; 1330nm; 1350nm; 1370nm; 1390nm; 1410nm; 1430nm; 1450nm; 1470nm; 1490nm; 1510nm; 1530nm; 1550nm; 1570nm; 1590nm; 1610nm

Shipping:

To Be Negotiated

Free Shipping

Can't deliver

to United States via {{now_chooseship?now_chooseship.name:''}}

Estimated delivery time : {{now_chooseship?now_chooseship.datemin:''}}-{{now_chooseship?now_chooseship.datemax:''}} days. See details

5-Year Warranty 30-Day Returns 30-Day Exchange

Stock:

{{parseInt(detail_data.left_num) ? detail_data.left_num +' in Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}} .

Quantity:

( Min. Order {{detail_data.prodInfo.minimum_ordered_quantity}} )

undeliverable

Total Price:

{{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.original_total_price }} ( {{ detail_data.displayed_price.rate_of_discount }}% OFF ) {{detail_data.displayed_price.ex_sell_type}}

Add to wish

Specifications

Specification
Videos
Matching Products
Download
Q&A
Customer Reviews

LINK-PP LS-CW591G-80C 1G SFP Specifications

LS-CW591G-80C functions as a 1G CWDM SFP optical transceiver designed with a 1590nm DFB laser transmitter and PIN photodetector. This module facilitates long-reach data links up to 80km utilizing standard single-mode fiber. It also supports real-time digital diagnostic monitoring interfaces for proactive optical link management.

LINK-PP Part Number	LS-CW591G-80C	Vendor Name	LINK-PP
Form Factor	SFP	Max Data Rate	1.25Gbps
Wavelength	1590nm	Max Cable Distance	80km
Connector	Duplex LC	Media	SMF
Transmitter Type	DFB	Receiver Type	PIN
TX Power	-1 to +4dBm	RX Power	-26 to -1dBm
Receiver Sensitivity	-26dBm	Receiver Overload	-1dBm
EMC (Electro Magnetic Comnatihilitv)	Supported	DDM	Supported
Operating Temperature Range	0 to 70°C	Protocols	SFP MSA、SFF-8472

Videos

Matching Products

Pictures

ID#

Description

Price

Stock

Add to Cart

Download

Product Drawing

PDF
LS-CWxx1G-80x.pdf

Questions & Answers
Ask a Question

No data

Q: Our switch is installed in a factory cabinet, and the internal temperature is usually around 55°C. Can we use this model? By I***n on 2026-03-26

A: The module can operate up to 70°C case temperature, but we recommend checking the actual module case temperature and ensuring sufficient ventilation in the cabinet. By admin on 2026-03-27
Q: We need remote monitoring because the fiber link is difficult to access. Does this module provide optical diagnostics? By C***r on 2026-02-05

A: Yes. It supports real-time DDM monitoring under SFF-8472, allowing compatible equipment to read information such as optical transmit power, receive power, temperature, voltage, and bias current. By admin on 2026-02-06
Q: We are replacing an old 1G CWDM optical transceiver in a storage network. Does this SFP transceiver support 1G Fibre Channel? By P***m on 2025-12-25

A: Yes. This LS-CW591G-80C SFP optical transceiver supports 1.063Gbps Fibre Channel, making it suitable for many 1G SAN and storage connectivity applications. By admin on 2025-12-26
Q: We have a 75km single-mode fiber route with several patch panels in between. Is this 80km CWDM SFP suitable? By L***r on 2025-07-05

A: It may be suitable, as this module supports transmission distances of up to 80km over single-mode fiber. However, 75km is close to the maximum distance, so the total link loss should be checked carefully. Please include fiber attenuation, connector and patch-panel loss, splice loss, and CWDM MUX/DEMUX insertion loss. By admin on 2025-07-06
Q: We are expanding our 1G CWDM network and already have a MUX/DEMUX with an available 1590nm port. Can this SFP be used on that channel for a long-distance single-mode fiber link? By F***n on 2025-05-21

A: Yes. The LS-CW591G-80C is a 1G CWDM SFP operating at 1590nm, so it can be installed in a matching 1590nm channel on a CWDM MUX/DEMUX. It is designed for duplex single-mode fiber links and supports transmission distances of up to 80km. By admin on 2025-05-22
