LP14BC01630 sfp+ 1x4 cage assembly press-fit with emi spring finger

LP14BC01630 SFP+ 1x4 Cage Assembly Press-Fit With EMI Spring Finger

Product summary

Product
LP14BC01630 SFP+ 1x4 Cage Assembly Press-Fit With EMI Spring Finger
SKU
200658
P/N
LP14BC01630
Price
$ 10.82
Stock
110 in Stock
Sold
900
Unit price $ 10.82
New Users: $ 10.00 Coupon on Your First Order
Code linkpp2610
For Order Over $ 1,000.00 Get $ 15.00 Off
Code Linkpp15
For Order Over $ 3,000.00 Get $ 50.00 Off
Code Linkpp50
For Order Over $ 5,000.00 Get $ 100.00 Off
Code Linkpp100
P/N: LP14BC01630SKU: 200658

LINK-PP originalDatasheet3D ModelAll downloads

Compatible:
LINK-PP
Compatible P/N:
LP14BC01630
Volume pricing Online tiers · larger qty or custom price on request
$ 10.820
1–99 pcs
$ 9.017
100–999 pcs
$ 7.729
1,000–4,999 pcs
$ 7.342
5,000–9,999 pcs
$ 6.956
≥10,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:
110 in Stock
Shipping:
$ 29.47
to United States via FedEx IP
Estimated delivery time : 3 - 6 days.
5-Year Warranty 15-Day Returns 15-Day Exchange
Warranty
  • Providing industry-leading 5-year warranty.
  • Read the table for details of all products' warranty.
Returns & Exchange
  • Refunds will be received about 5 business days after the receipt of returned items.
  • Items in stock for replacement can be shipped within 1 business day.
  • Read the full return policy for details.
Free shipping over $ 99.00.
Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).
Quantity:
Total Price:
$ 10.82

LINK-PP LP14BC01630 SFP+ 1x4 Cage Assembly Press-Fit With EMI Spring Finger

LINK-PP Part Number LP14BC01630 Part Status Active
Product Type Cage Assembly Form Factor SFP+
Max Data Rate 16 Gbps Features EMI Shielded
Port Matrix Configuration 1×4 Number of Ports 4
Included Connector No Included Heat Sink Yes
Included Lightpipe Yes EMI Containment Feature Type Spring Fingers
Termination Press-Fit Mounting Type Through Hole, Right Angle
Tail Length (Inches/mm) 0.081/2.05 Recommended PCB Thickness (Inches/mm) 0.059/1.50 (REF)
Length (Inches/mm) 2.157/54.80 (REF) Width (Inches/mm) 2.254/57.25 (REF)
Height (Inches/mm) 0.626/15.90 Cage Material Stainless Steel
Contact Plating None Cage Plating Nickel
Operating Temperature Range -40 to +85°C Packaging Tray

Model Comparison Table

LINK-PP

Matching Products

Pictures ID# Description Price Stock Add to Cart

Download

Product Drawing LP14BC01630.pdf

Questions & Answers

No questions yet

Be the first to ask about specs, compatibility, or lead time.

Ask a Question
  • A:
    Expect 3.2kN to 3.6kN on a 2.0mm board, slightly higher than on 1.6mm because the eye compresses more. Use a flat rock tool and a backing plate that covers the full 57.25mm footprint plus 5mm on each side. A small plate that only covers the center will let the ends flex and you will crack the outer vias. Press at about 25mm per minute, and stop if force exceeds 4kN. by LINK-PP Technical Support
  • A:
    Mechanically yes, any SFP form factor module seats and latches in this cage. Electrically the cage is passive so it does not care about speed, 1G and 10G both work. The limit is your host port, an SFP+ port will usually negotiate down to 1G with a 1G module but not always, it depends on the PHY. For a mixed deployment this cage is the safe choice. by LINK-PP Technical Support
  • A:
    Each spring finger needs about 2mm by 1.5mm of bare metal contact, and there are 8 per side, so plan for a 16mm by 3mm masked pad on each side of the cage. The surface must be bare metal, not painted or anodized, the fingers cannot bite through coating. Compression should be 0.3mm to 0.5mm. If your panel is powder coated, mask the pad area before coating. by LINK-PP Technical Support
  • A:
    No, the light pipe version uses a different cage frame with molded retention slots for the pipes. You cannot retrofit pipes into the plain cage, there is nothing to clip them to. If there is any chance you will want indicators later, buy the light pipe version now, the price difference is about 40 cents per port and it is much cheaper than a cage swap in production. The footprint and height are identical. by LINK-PP Technical Support

Customer Reviews

  • 4.9

    29 Reviews

  • 5 Stars
    93%
    4 Stars
    7%
    3 Stars
    0%
    2 Stars
    0%
    1 Star
    0%
  • All Reviews (29)
No data
E***e
Colombia
Verified Purchase
5.0
2026-11-16
Four seats, press-fit, no light pipe, good.
M***d
Czech Republic
Verified Purchase
5.0
2026-10-17
Four openings in one body means one insertion step and one cutout on the plate, 57.25 mm across is four SFP+ pitches, and without a light pipe the status comes from the module front, which is fine for a rear facing card.
L***d
Argentina
Verified Purchase
4.0
2026-09-18
The tray had no padding and one cage came bent, but the pins were straight. Four seats pressed in with one stroke and the springs bit every opening, no fuss.
R***w
Netherlands
Verified Purchase
5.0
2026-08-19
54.80 mm depth, and the rail behind the panel clears it, no drama. ;)
H***g
Portugal
Verified Purchase
4.0
2026-06-12
Cages press in fine and all four ports work, but two of the fifty arrived with a bent EMI finger because the inner box had no foam. Bent it back, no functional issue, but ship these with better protection.
