LP0009NLE 10 100 base-t single port lan magnetics transformer modules for pc card
Click to open expanded view

LP0009NLE 10/100 BASE-T Single Port Lan Magnetics Transformer Modules For PC Card

Product summary

Product
LP0009NLE 10/100 BASE-T Single Port Lan Magnetics Transformer Modules For PC Card
SKU
179247
P/N
LP0009NLE
Price
$ 0.80
Stock
1 in Stock
Sold
35K
Unit price $ 0.80
New Users: $ 10.00 Coupon on Your First Order
Code linkpp2610
For Order Over $ 1,000.00 Get $ 15.00 Off
Code Linkpp15
For Order Over $ 3,000.00 Get $ 50.00 Off
Code Linkpp50
For Order Over $ 5,000.00 Get $ 100.00 Off
Code Linkpp100
P/N: LP0009NLESKU: 179247

LINK-PP originalDatasheetAll downloads

Compatible:
Pulse
LINK-PP
Compatible P/N:
LP0009NLE
Volume pricing Online tiers · larger qty or custom price on request
$ 0.800
1–9 pcs
$ 0.800
10–349 pcs
$ 0.608
350–1,399 pcs
$ 0.576
1,400–9,799 pcs
$ 0.552
9,800–20,999 pcs
$ 0.528
≥21,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:
1 in Stock
Shipping:
Free Shipping
to United States via FedEx IP
Estimated delivery time : 3 - 6 days.
5-Year Warranty 15-Day Returns 15-Day Exchange
Warranty
  • Providing industry-leading 5-year warranty.
  • Read the table for details of all products' warranty.
Returns & Exchange
  • Refunds will be received about 5 business days after the receipt of returned items.
  • Items in stock for replacement can be shipped within 1 business day.
  • Read the full return policy for details.
Free shipping over $ 600.00.
Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).
Quantity:
MOQ 10000 SPQ 350
Total Price:
$ 8000.00
Packaging Details
350 pcs
1400 pcs
Reel
37×37×25 cm
0.005 kg
7 kg

LINK-PP LP0009NLE 10/100 BASE-T Single Port Lan Magnetics Transformer Modules For PC Card (SMD,16 Pin)


LINK-PP Part Number
LP0009NLE Transformer Type
Lan Transformer
Part Status
Active Turns Ratio - Primary:Secondary
1:1 Transmitter, 1:1 Receiver
Construction
OPEN FRAME
Application-Lan
Ethernet(Non PoE)
Number of Ports
Single PortSpeed
10/100 Base-T
Package
Tape & ReelCores per Port
4
AutomDX
YesComment

SAME AS NL VERSION

PIN number
16
Mounting Type

Surface Mount

Package Height (Inches/mm)
0.081/2.08Package Length (Inches/mm)0.560/14.22
Package Width (Inches/mm)
0.560/14.22Temperature
0℃ TO +70℃
Turns Ratio RX/TX
1CT:1CT
Configuration RX/TX
T,C,S


LINK-PP

Matching Products

Pictures ID# Description Price Stock Add to Cart

Download

Product Drawing LP0009NLE.pdf

Questions & Answers

No questions yet

Be the first to ask about specs, compatibility, or lead time.

Ask a Question
  • A:
    Usually yes, because sixteen pins on a single port is a standard pattern and the family is built around it. What changes is the height and sometimes the pin length, so check the drawing for the part you intend to substitute and confirm the hole size. The electrical ratings are not automatically the same either, so compare the turns ratio and the isolation before swapping a reel. by LINK-PP Technical Support
  • A:
    Height and process decide it. The open frame is thinner, cheaper and dissipates better, so it suits a board with an enclosure and a wash-free process. A potted part hides the winding, survives aqueous cleaning and handling, and costs more while sitting taller. If the board goes through a washer or the part is exposed to a technician's fingers, potted is the safer choice. by LINK-PP Technical Support
  • A:
    It swaps the transmit and receive pairs inside the magnetics, so a straight lead and a crossed lead both work at the connector. The PHY still negotiates speed and duplex, and auto MDI-X inside the PHY does the same job electrically. Having both is not a fault: the magnetics decide which pair arrives where, and the PHY decides the rate. by LINK-PP Technical Support
  • A:
    No. This is a data side magnetic with no path for driving a remote device and no current rating for one. A port that has to serve a camera needs a different transformer and a connector built for it, and the footprint does not tell you which is which. Check the part number against the powered version of the same family before committing, because the two look identical once they are on a board. by LINK-PP Technical Support
