LPJG17037A4NL 1000 base-t 2x1 port gigabit rj45 magjack yellow&green yellow&green led
Click to open expanded view

LPJG17037A4NL 1000 Base-T 2X1 Port Gigabit RJ45 Magjack Yellow&Green/Yellow&Green LED

Product summary

Product
LPJG17037A4NL 1000 Base-T 2X1 Port Gigabit RJ45 Magjack Yellow&Green/Yellow&Green LED
SKU
173127
P/N
LPJG17037A4NL
Price
$ 9.92
Stock
1683 in Stock
Sold
28.5K
Unit price $ 9.92
New Users: $ 10.00 Coupon on Your First Order
Code linkpp2610
For Order Over $ 1,000.00 Get $ 15.00 Off
Code Linkpp15
For Order Over $ 3,000.00 Get $ 50.00 Off
Code Linkpp50
For Order Over $ 5,000.00 Get $ 100.00 Off
Code Linkpp100
P/N: LPJG17037A4NLSKU: 173127

LINK-PP originalDatasheetAll downloads

Compatible P/N:
LPJG17037A4NL
Volume pricing Online tiers · larger qty or custom price on request
$ 9.920
1–99 pcs
$ 8.135
100–599 pcs
$ 7.143
600–1,199 pcs
$ 5.457
1,200–5,999 pcs
$ 4.663
≥6,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:
1683 in Stock
Shipping:
$ 29.47
to United States via FedEx IP
Estimated delivery time : 3 - 6 days.
5-Year Warranty 15-Day Returns 15-Day Exchange
Warranty
  • Providing industry-leading 5-year warranty.
  • Read the table for details of all products' warranty.
Returns & Exchange
  • Refunds will be received about 5 business days after the receipt of returned items.
  • Items in stock for replacement can be shipped within 1 business day.
  • Read the full return policy for details.
Free shipping over $ 600.00.
Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).
Quantity:
SPQ 40
Total Price:
$ 9.92
Packaging Details
40 pcs
640 pcs
Tray
37×30×30 cm
0.012 kg
7.5 kg

LINK-PP LPJG17037A4NL 1000 Base-T RJ45 Ethernet MagJack for Network Cardand Automation (2x1 Port, Yellow&Green/Yellow&Green LED)

The LPJG17037A4NL supports speed 100/1000 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Network Card, Optical Terminal ,Game Controller and Automation.

LINK-PP Part Number: LPJG17037A4NL Connector Type Jack
Part Status Active Mounting Type Through Hole
Number of Positions/Contacts 10p8c (RJ45, Ethernet) Application-Lan Ethernet(NoN PoE)
Number of Ports 2x1 Port Speed 100/1000 Base-T
Latch Both Cores per Port 8
Orientation 90° Angle (Right) PCB Mount Angle

SIDE ENTRY

Shield EMI Tabs With LED Option

Yellow&Green/Yellow&Green

PCB FR4 PCB Retaining Post

T POST

Package Height (Inches/mm) 1.004/25.50 Package Length (Inches/mm)

1.130/28.70

Package Width (Inches/mm) 0.676/17.16 Temperature -40℃ TO +85℃
Bst Circuit Yes AutomDX

YES

Diodes No Contact Mating Area Plating

GOLD 6u"/15u"/30u"

Turns Ratio RX/TX 1CT:1CT Configuration RX/TX

T,C

LINK-PP

Matching Products

Pictures ID# Description Price Stock Add to Cart

Download

Product Drawing LPJG17037A4NL.pdf

Questions & Answers

No questions yet

Be the first to ask about specs, compatibility, or lead time.

Ask a Question
  • A:
    The housing holds two emitters per port, four in total across the stack, and the PHY has to supply a drive line for each one. Link and activity assignment follows the controller wiring rather than the colour of the plastic, so we marked both positions on the silkscreen and verified them with traffic flowing. Current limiting parts sit on the board. Check the common connection in the datasheet before laying out the resistor network. by LINK-PP Technical Support
  • A:
    Purely mechanical. It describes how the plug retention is arranged on a two by one housing, and it has no effect on the magnetics or the pinout. What it does change is the direction the cords exit and how much finger room the panel needs around the two openings. We standardised the cutout across the pair so the same harness worked on both. Decide it from the enclosure drawing rather than the circuit diagram. by LINK-PP Technical Support
  • A:
    It describes ten contact positions in an eight conductor modular interface, the usual extra two being used for the LED or auxiliary connections inside a gigabit jack. The cable side still uses the four data pairs of a standard RJ45 plug, so a normal patch lead mates without anything special. Check the datasheet pinout before wiring the lamps, because the extra contacts are easy to misassign. We verified both port LEDs on a live link. by LINK-PP Technical Support
  • A:
    Each port needs four matched pairs, so eight pairs converge on a narrow seventeen millimetre wide body and the inner rows have to be fanned out carefully. We broke the stack out on two inner layers and kept the pairs from crossing under the magnetics. The lower port sits closer to the board, which makes its latch harder to reach with a thick panel. Leave a few millimetres below that opening and mock up the cutout first. by LINK-PP Technical Support
