X Multiple XRJD-S-24-8-8-W26 Compatible LINK-PP LPJE108XA62NL Tab Up Red&Yellow/Green LED 2X4 Port Jack RJ45 without Integrated Magnetics

Product summary

Product
X Multiple XRJD-S-24-8-8-W26 Compatible LINK-PP LPJE108XA62NL Tab Up Red&Yellow/Green LED 2X4 Port Jack RJ45 without Integrated Magnetics
SKU
104469
P/N
LPJE108XA62NL
Price
$ 7.50
Stock
1175 in Stock
Sold
9.5K
Unit price $ 7.50
New Users: $ 10.00 Coupon on Your First Order
Code linkpp2610
For Order Over $ 1,000.00 Get $ 15.00 Off
Code Linkpp15
For Order Over $ 3,000.00 Get $ 50.00 Off
Code Linkpp50
For Order Over $ 5,000.00 Get $ 100.00 Off
Code Linkpp100
Manufacture: LINK-PPP/N: LPJE108XA62NLSKU: 104469

Compatible with X Multiple XRJD-S-24-8-8-W26Datasheet3D ModelAll downloads

Compatible P/N:
XRJD-S-24-8-8-W26
Volume pricing Online tiers · larger qty or custom price on request
$ 7.500
1–99 pcs
$ 7.500
100–999 pcs
$ 6.750
1,000–4,999 pcs
$ 6.525
5,000–9,999 pcs
$ 6.375
10,000–14,999 pcs
$ 6.150
≥15,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:
1175 in Stock
Shipping:
$ 29.47
to United States via FedEx IP
Estimated delivery time : 3 - 6 days.
5-Year Warranty 15-Day Returns 15-Day Exchange
Warranty
  • Providing industry-leading 5-year warranty.
  • Read the table for details of all products' warranty.
Returns & Exchange
  • Refunds will be received about 5 business days after the receipt of returned items.
  • Items in stock for replacement can be shipped within 1 business day.
  • Read the full return policy for details.
Free shipping over $ 600.00.
Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).
Quantity:
SPQ 10
Total Price:
$ 7.50
Packaging Details
10 pcs
200 pcs
Tray
37.5×24×34.5 cm
0.071 kg
14.2 kg

X Multiple XRJD-S-24-8-8-W26 Compatible LINK-PP LPJE108XA62NL Jack RJ45 without Integrated Magnetics for SMPS and Embedded Main Board(2X4 Port,Tab Up,Red&Yellow/Green LED)

The LPJE108XA62NL supports speed 10/100 Base-T, it is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001, ISO14001 standards. It can be used to support application, such as SMPS,Embedded Main Board, switch and router.


LINK-PP Part Number:
LPJE108XA62NL X Multiple Part Number XRJD-S-24-8-8-W26
Part Status
Active Connector Type
Jack
Number of Positions/Contacts
8p8c (RJ45, Ethernet) Application-Lan
-
Number of Ports
2x4 Port
Speed
-
Latch
BothCores per Port
-
Orientation
90° Angle (Right)PCB Mount Angle

SIDE ENTRY

Shield EMI Tabs
With LED Option

Red&Yellow/Green

PCB
FR4PCB Retaining Post

T POST

Package Height (Inches/mm)
1.00/25.40Package Length (Inches/mm)

1.108/28.15

Package Width (Inches/mm)
2.514/63.86
Temperature
-40℃ TO +85℃
Bst Circuit
YesAutomDX

YES

Diodes
NoContact Mating Area Plating

GOLD 6u"/15u"/30u"

Turns Ratio RX/TX
1CT:1CTConfiguration RX/TX

T,C

LINK-PP

Matching Products

Pictures ID# Description Price Stock Add to Cart

Download

Product Drawing LPJE108XA62NL.pdf

Questions & Answers

No questions yet

Be the first to ask about specs, compatibility, or lead time.

Ask a Question
  • A:
    The 2x4 housing leaves the rim free of stamped EMI fingers. Contacts go from the cavity straight to the tail with no metal can. Whatever shielding you need must come from the board side. Your panel artwork sets where that return lands. by LINK-PP Technical Support
  • A:
    The eight mouths form two rows within one shell on this item. Each opening keeps the usual 8P8C pitch. No tail set strays across to a neighbouring port. Your board file sets the row pitch and its tolerance. by LINK-PP Technical Support
  • A:
    Three colour windows sit on the front and run as bare leads to the board. We list no colour as a fixed link indicator. The drive current is supplied from your board. Your firmware and silkscreen assign each colour its meaning. by LINK-PP Technical Support
  • A:
    Eight mouths stack in a single tab up body on this part. Each mouth keeps separate contacts and tails of its own. There is no winding concealed in the shell at any port. Your board layout brings any transformer the link wants. by LINK-PP Technical Support
