Breadcrumb: Home; Products; Integrated RJ45 Connector; Single Port RJ45 Connector; 10/100 Base-T RJ45 Connector; 94219

Belfuse L826-1X1T-06-F Compatible LINK-PP LPJK0005AONL 10/100 Base-T 8P8C Modular RJ45 Connectors Tab Up Orange&Green/Yellow Led

Name: Belfuse L826-1X1T-06-F Compatible LINK-PP LPJK0005AONL 10/100 Base-T 8P8C Modular RJ45 Connectors Tab Up Orange&Green/Yellow Led
Brand: LINK-PP
SKU: 94219
Price: 3.61 USD
Availability: InStock
Rating: 5 (61 reviews)

Product: Belfuse L826-1X1T-06-F Compatible LINK-PP LPJK0005AONL 10/100 Base-T 8P8C Modular RJ45 Connectors Tab Up Orange&Green/Yellow Led
SKU: 94219
P/N: LPJK0005AONL
Price: $ 3.61
Stock: 1365 in Stock
Sold: 4.5K
Product URL: https://www.l-p.com/products/433977.htm

61 Reviews

4 Questions

4.5KSold

Unit price $ 3.61

New Users: $ 10.00 Coupon on Your First Order

Code linkpp2610

For Order Over $ 1,000.00 Get $ 15.00 Off

Code Linkpp15

For Order Over $ 3,000.00 Get $ 50.00 Off

Code Linkpp50

For Order Over $ 5,000.00 Get $ 100.00 Off

Code Linkpp100

Manufacture: LINK-PPP/N: LPJK0005AONLSKU: 94219

Compatible with Belfuse L826-1X1T-06-FDatasheet 3D Model All downloads

Compatible:: Belfuse; LINK-PP

Compatible P/N:: 0826-1X1T-06-F; L826-1X1T-06-F

Volume pricing Online tiers · larger qty or custom price on request

$ 3.610

1–99 pcs

$ 2.958

100–599 pcs

$ 2.597

600–1,199 pcs

$ 1.984

1,200–5,999 pcs

$ 1.695

≥6,000 pcs

Need a qty beyond these tiers, or to negotiate price?

Stock:

1365 in Stock

Shipping:

$ 29.47

to United States via FedEx IP

Estimated delivery time : 3 - 6 days.

5-Year Warranty 15-Day Returns 15-Day Exchange

Free shipping over $ 600.00.

Or ship with your own UPS / FedEx / DHL account at checkout ($ 0.00 shipping).

Quantity:

SPQ 60

Total Price:

$ 3.61

Packaging Details

SPQ:60 pcs
Qty/carton:960 pcs
Package:Tray
Carton size:37×30×30 cm
N.W/pcs:0.011 kg
G.W/carton:10.1 kg

Description
Specification
Matching Products
Download
Q&A
Customer Reviews

Belfuse L826-1X1T-06-F Compatible LINK-PP LPJK0005AONL 10/100 Base-T 8P8C Modular RJ45 Connectors for Smart Home and The Handheld Device (1x1 Port, Tab Up, Orange&Green/Yellow Led)

The LPJK0005AONL supports speed 10/100 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Industrial PC, Smart Home, The Handheld Device and Game Controller.

LINK-PP Part Number:	LPJK0005AONL	Belfuse Part Number	L826-1X1T-06-F
Part Status	Active	Connector Type	Jack
Number of Positions/Contacts	6p8c (RJ45, Ethernet)	Application-Lan	Ethernet( NoN PoE )
Number of Ports	1x1 Port	Speed	10/100 Base-T
Latch	UP	Cores per Port	4
Orientation	90° Angle (Right)	PCB Mount Angle	SIDE ENTRY
Shield EMI Tabs	With	LED Option	Orange&Green/Yellow Leds
PCB	FR4	PCB Retaining Post	T POST
Package Height (Inches/mm)	0.531/13.50	Package Length (Inches/mm)	1.30/33.02
Package Width (Inches)	0.654/16.60	Temperature	0℃ TO 70℃
Bst Circuit	Yes	AutomDX	YES
Diodes	No	Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Turns Ratio RX/TX	1CT:1CT	Configuration RX/TX	T,C
