LINK-PP is a leading global manufacturer specializing in high-performance RJ45 connectors, optical transceivers, SFP modules, fiber optic cages and connectors, LAN transformers, and modular jacks. Serving OEMs, telecom operators, data centers, and networking integrators, LINK-PP delivers reliable, scalable solutions for next-generation communication networks. Our products enable high-speed data transmission, robust connectivity, and efficient network infrastructure deployment worldwide.
Transceiver Optik | Modul SFP
Fiber Optic Transceiver is an interconnect component used to convert electrical signals to optical (light) signals and optical signals to electrical signals. Acts as both a transmitter and a receiver. In fiber optics, this data is sent in the form of light pulses at very high speeds and across long distances. SFP Module is a small form factor pluggable optical transceiver or miniGBIC (gigabit interface converter) for transmitting and receiving data over fiber. Commonly used to interconnect fiber cables to network switches and other communication devices, such as industrial Ethernet switches and media converters.
Karakteristik utama
1. Fiber Mode: Multimode fibers, Singlemode fibers
2. Transfer Rate: 1G, 2G, 4G / 10G, 25G, 40G, 100G/ 200G, 400G, 800G.
3. Transmission Distance: Multimode SFP 100m / 550m, Single-mode SFP 2km up to 200km
4. Wavelength Options: 850nm, 1310nm or 1550nm
5. Connector Type: SC, LC, MPO, and ST
Fitur
● Hot-swappable design to maximize uptime and simplify serviceability
● Bidirectional data transmission is possible via fiber optic cables
● Desain kokoh untuk meningkatkan keandalan
● Supports Digital Optical Monitoring (DOM) capability, providing real-time monitoring and reporting of key parameters such as optical power, temperature, and voltage.
● MSA (Multi-Source Agreement) and RoHS Compliance
Operasi Kisaran Suhu
● Commercial temperature range (COM): 0 to 70°C (32 to 158°F)
● Extended temperature range (EXT): -5°C to 85°C (23 to 185°F)
● Industrial temperature range (IND): -40 to 85°C (-40 to 185°F)
● Storage temperature range: -40 to 85°C (-40 to 185°F)
Sangkar dan Konektor Serat Optik
SFP transceiver interface sockets and cages are designed for small form factor pluggable transceivers. Mates with SFP, SFP+, ZSFP+, QSFP, QSFP+, zQSFP+,QSFP28, QSFP56, QSFP-DD. Offering a secure and reliable interface for high-speed data transmission in fiber optic and Ethernet applications.
Fitur utama
1. 1x1,1xN, 2xN Single, Ganged or Stacked Platform
2. With & Without Heatsinks, Lightpipes, EMI Shielding Options
3. 1G, 5G, 10G, 40G, 100G & 400G Performance
4. Press Fit, SMT & THT Soldering Package
5. Compliant with Small Form Factor industry standards
Konektor RJ45 Terintegrasi
LINK-PP integrated RJ45 connector incorporates the ethernet signal magnetics used for filtering and isolation. The integrated design minimizes the overall PCB footprint and enables excellent EMI performance. Provides safe and reliable connections and is suitable for various network devices such as switches and routers. The following are the key Features supported by the LINK-PP RJ45 connector series.
Fitur utama
1. Data Rates: 10Base-T, 100Base-TX, 1000Base-T, 2.5GBase-T, 5GBase-T, 10GBase-T and HDBase-T
2. Number of Ports: 1×1, 1xN, 2xN, RJ45/USB
3. Tab Direction: Latch-Up, Latch-Down, Up & Down
4. PoE Function: Non-PoE, PoE, PoE+, PoE++, 2pr PoE, 4pr PoE
5. Mounting Type: Through-hole, Surface Mount, Pin-in-Paste and Press-Fit
6. Shielded / LED Option： With, Without
7. Operating Temperature Range: 0°C to +70 °C, -40°C to +85 °C
LAN Transformer
Local area network (LAN) transformers, also known as Ethernet transformers, filter and isolate signals for network devices including Ethernet Adapters, Hubs, Routers, Network Switches, IP cameras, Network Interface Cards (NICs), Communication Equipment, IoT applications. LINK-PP LAN interface and Ethernet application magnetics with fully automated winding, assembly, testing, and packaging to ensure consistent performance. Compatible with all major PHY vendors, providing circuit isolation to maintain signal integrity.
Fitur utama
1. Data Rate: 10 BASE-T, 100 BASE-TX, 1000 BASE-T, 2.5G BASE-T, 5G BASE-T, 10G BASE-T
2.Application -LAN: ETHERNET(non-PoE), PoE, PoE+, CHOKE, TOKEN RING, PoE++
3. Single, Dual, Quad Packages
4. Mounting Type: THT, SMT, PCMCIA, BGA BUMP GRID ARRAY, SMD
5. Operating Temperature Range: 0 to +70°C -40°C to +85°C -40°C to +105°C
6. Compliant with HDBaseT, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at and upcoming IEEE 802.3bt standards
