Cisco CWDM-SFP10G-1530-10 Compatible LINK-PP LS-CW5310-10C SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 15310nm, 10km, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 10km transmission distance with SMF.The transceiver consists of three sections: a uncooled DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472

Cisco CWDM-SFP10G-1510-10 Compatible LINK-PP LS-CW5110-10C SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1510nm, 10km, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 10km transmission distance with SMF.The transceiver consists of three sections: a uncooled DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472

Cisco CWDM-SFP10G-1490-10 Compatible LINK-PP LS-CW4910-10C SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1490nm, 10km, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 10km transmission distance with SMF.The transceiver consists of three sections: a uncooled DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472

Cisco CWDM-SFP10G-1470-10 Compatible LINK-PP LS-CW4710-10C SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1470nm, 10km, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 10km transmission distance with SMF.The transceiver consists of three sections: a uncooled DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472

Cisco CWDM-SFP10G-1350-I Compatible LINK-PP LS-CW3510-40I SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1350nm, 40km, Industrial, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 40km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and

Cisco CWDM-SFP10G-1330-I Compatible LINK-PP LS-CW3310-40I SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1330nm, 40km, Industrial, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and

Cisco CWDM-SFP10G-1310-I Compatible LINK-PP LS-CW3110-40I SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1310nm, 40km, Industrial, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and

Cisco CWDM-SFP10G-1290-I Compatible LINK-PP LS-CW2910-40I SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1290nm, 40km, Industrial, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and

Cisco CWDM-SFP10G-1270-I Compatible LINK-PP LS-CW2710-40I SFP+ 10G CWDM Duplex LC/UPC Optical Transceiver Module for Transmission (SMF, 1270nm, 40km, Industrial, DOM)The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement and

Cisco QSFP-40G-SR4 Compatible LINK-PP LQ-M8540-SR4C QSFP+ 40GBASE-SR4 MPO-12/UPC Optical Transceiver Module(MMF, 850nm, 150m, DOM)The LQ-M8540-SR4C QSFP+ module adopts 12 Fibers MTP/MPO Male connectors, reaching a link up to 150m over OM4 MMF (100m over OM3). This transceiver is compliant with QSFP+ MSA, IEEE 802.3ba 40GBASE-SR4 and breakout to 4x10GBASE-SR standard. At the same time, it is completely interoperable with all standard 40GBASE-SR4 interfaces. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP+ MSA, to allow access to real-time

Cisco SFP-10G-T-80 Compatible LINK-PP LP-RJ45TG-8YC 10GBASE-T SFP+ Transceiver Module(Copper, 80m, RJ45)LP-RJ45TG-8YC Copper Small Form Pluggable (SFP) transceivers are high performance, cost effective module compliant with the 10G Ethernet and 10GBASE-T standards as specified in IEEE 802.3az, which supporting 10Gbps data- rate up to 80 meters reach over unshielded twisted-pair category 6a/7 cables. The module provides standard serial ID information compliant with SFP+ MSA, which can be accessed with address of A0h via the 2wire serial EEPROM protocol.

Cisco SFP-10G-T-S-I Compatible LINK-PP LP-RJ45TG-3YI SFP+ 10GBASE-T Copper 30m RJ-45 Transceiver Module (Copper, Industrial, 30m, RJ-45)LP-RJ45TG-3YI Copper Small Form Pluggable (SFP) transceivers are high performance, cost effective module compliant with the 10G Ethernet and 10GBASE-T standards as specified in IEEE 802.3az, which supporting 10Gbps data- rate up to 30 meters reach over unshielded twisted-pair category 6a/7 cables. The module provides standard serial ID information compliant with SFP+ MSA, which can be accessed with address of A0h via the 2wire serial EEPROM protocol.

Cisco SFP-10G-T-X Compatible LINK-PP LP-RJ45TG-3YC 10GBase-T SFP+ Transceiver Module(Copper, 30m, RJ-45)LP-RJ45TG-3YC Copper Small Form Pluggable (SFP) transceivers are high performance, cost effective module compliant with the 10G Ethernet and 10GBASE-T standards as specified in IEEE 802.3az, which supporting 10Gbps data- rate up to 30 meters reach over unshielded twisted-pair category 6a/7 cables. The module provides standard serial ID information compliant with SFP+ MSA, which can be accessed with address of A0h via the 2wire serial EEPROM protocol.

Cisco SFP-10G-BX100U Compatible LINK-PP LS-BL495510-A0C 10GBASE-BX80-U BiDi Simplex SFP+ Optical Transceiver Module(SMF, 1490nm-TX/1550nm-RX 100km, LC, DOM)The LS-BL495510-A0C SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 100km transmission distance with SMF. The transceiver consists of three sections: a Cooled EML laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi Source

Cisco QSFP-100G-DR-S Compatible LINK-PP LQ-SM31100-DR1C 100GBASE-DR QSFP28 Duplex LC/UPC SMF Optical Transceiver Module (Single Lambda, SMF, 1310nm, 500m, LC, DOM)The LQ-SM31100-DR1C 100GBASE-DR Single Lambda QSFP optical transceiver module is designed for use in 100GBASE Ethernet throughput up to 500m over single mode fiber (SMF) using a wavelength of 1310nm via duplex LC connectors. The 100 Gigabit Ethernet signal is carried over a single wavelength using onboard PAM4 modulation and FEC. The transceiver includes a Broadcom chip to convert the 4x25G NRZ electrical signals to a

Cisco QSFP-4X10G-LR-S Compatible LINK-PP LQ-M3140-LR4C QSFP+ 4 x 10GBASE-LR Optical Transceiver Module (SMF, 1310nm, 10km, MTP/MPO-12, DOM)The transceiver is designed for 10km optical communication applications,which compliant to 40GBASE-LR4 of the IEEE P802.3ba standard. The module converts 4 inputs channels (ch) of 10Gb/s electrical data to 4 optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 channels signals, and converts them to 4 channel output
