DW-SFP10G80-50-I SFP+ transceiver connects long-distance 10G DWDM optical links over single-mode fiber with a reach of up to 80km via a duplex LC interface. Built with an integrated C-band EML laser and APD receiver, it guarantees stable wavelength locking and adequate link margins under harsh -40°C to 85°C operating conditions.
Generic Part Number
DW-SFP10G80-50-I
Vendor Name
LINK-PP
Form Factor
SFP+
Max Data Rate
10.7Gbps
Wavelength
1537.40nm
Max Cable Distance
80km
Connector
Duplex LC
Media
SMF
Transmitter Type
EML
Receiver Type
APD
TX Power
-1 to +5dBm
RX Power
-23 to -6dBm
Receiver Sensitivity
-23dBm
DDM/DOM
Supported
Operating Temperature Range
-40 to +85°C
Protocols
10GBASE-ZR/ZW, SDH STM64, SFF-8431, SFF-8472
Key Features of Generic DW-SFP10G80-50-I Compatible LINK-PP 10G SFP+
Generic DW-SFP10G80-50-I Compatible LINK-PP module is an industrial-grade 10GBASE-DWDM SFP+ transceiver built for long-haul optical transport over single-mode fiber. It transmits across distances up to 80km on the fixed 1537.40nm DWDM wavelength and includes digital diagnostic monitoring for real-time status checks.
The transceiver features an industry-standard SFP+ form factor that plugs directly into compatible switch or router ports. Built for harsh operating environments, it functions reliably across an industrial temperature range of -40°C to +85°C.
DW-SFP10G80-50-I: 10 Gbps Connectivity for Industrial Optical Aggregation
This optical module delivers continuous 10Gbps data rates to aggregate network traffic across high-bandwidth industrial switches. It provides steady, full-duplex data flow for demanding Ethernet transmission tasks.
DW-SFP10G80-50-I Module with DWDM Technology for Fiber Efficiency
Dense wavelength division multiplexing technology allows the module to send data over a dedicated optical channel alongside other wavelengths. This setup expands total network capacity over existing fiber lines without running additional cables.
DW-SFP10G80-50-I Module with 1537.40nm Wavelength
The transmitter operates at a fixed central wavelength of 1537.40nm, matching ITU-T DWDM channel C50. It maintains a stable light frequency to prevent interference with neighboring channels on the same fiber.
An internal EML transmitter and APD receiver setup allows data links to span distances up to 80km on single-mode fiber. This capability connects distant network switches without requiring extra inline repeaters.
DW-SFP10G80-50-I Module with Duplex LC Interface
Dual optical ports utilize a duplex LC connector to attach standard single-mode patch cords. The click-to-latch design provides an easy, secure connection that keeps the fiber precisely aligned.
DW-SFP10G80-50-I Module with DDM for Real-Time Monitoring
Integrated digital diagnostic monitoring tracks key operational values, including optical power, operating temperature, laser bias current, and supply voltage. Network administrators can read these metrics through the switch interface to quickly evaluate link status.
Generic DW-SFP10G80-50-I Compatible LINK-PP 10G DWDM SFP+ module is manufactured under ISO 9001 quality management standards and complies fully with CE, RoHS, and FCC regulatory requirements.
Each DWDM transceiver module passes strict bit-error rate, optical spectrum, and eye-pattern tests prior to delivery to ensure clean signal quality and stable field operation.
DW-SFP10G80-50-I Quality Certifications
Official regulatory compliance confirms that the module meets international safety, environmental, and electromagnetic compatibility standards.
This product is in conformity with ISO9001. This system is valid to a company engaging in development, production and supply service of fiber optical products. Please contact us to learn more.
ISO/IEC 27001 is an international standard for managing and processing information security. This standard is jointly developed by the International Organization for Standardization (ISO) and the International Electrotechnical Commission (IEC). It sets out requirements for establishing, implementing, maintaining, and continually improving an information security management system (ISMS). Ensuring the confidentiality, integrity, and availability of organizational information assets, obtaining an ISO 27001 certificate means that the enterprise has passed the audit conducted by a certification body, proving that its information security management system has met the requirements of the international standard. Please contact us to learn more.
This product is in conformity with ISO14001.It is intended for use by an organization seeking to manage its environmental responsibilities in a systematic manner that contributes to the environmental pillar of sustainability. Please contact us to learn more.
ISO 45001 is a global standard that sets out the requirements for an occupational health and safety management system (OH&SMS).
REACH is a European Union regulation concerning the Registration, Evaluation, Authorization and Restriction of Chemicals. It came into force on 1st June 2007 and replaced a number of European Directives and Regulations with a single system. The regulation aims to protect human health and environmental safety, maintain and improve the competitiveness of the EU chemical industry, and develop innovative capabilities for non-toxic and harmless compounds to prevent market fragmentation, increase the transparency of the use of chemicals, promote non-animal experiments, and pursue sustainable social development.Please contact us to learn more.
This product meets the applicable requirements of Directive (EU) 2015/863 of RoHS. It restricts the use of 10 hazardous materials in the manufacture of various types of electronic and electrical equipment: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls, polybrominated diphenyl ethers, and four different phthalates. Please contact us to learn more.
This product fully accords with the FCC, which aims to manage the radio wave and magnetic fields more reasonably. Please contact us to learn more.
CB is an international system operated by IECEE. This product is based on IEC standards for testing the safety performance of electrical products. Please contact us to learn more.
This product fully accords with UKCA (UK Conformity Assessed) certificate, which signifies that it meets all relevant quality standards as well as health and safety requirements. Please contact us to learn more.
UL certification is a non-mandatory certification in the United States,mainly testing and certification of product safety performance.Its ultimate purpose is to obtain products with a fairly safe level for the market,and to contribute to ensuring human health and property safety.Please contact us to learn more.
DW-SFP10G80-50-I Certified for Reliable Host-Device Compatibility
Extensive switch interoperability testing guarantees plug-and-play operation and seamless link recognition across major networking brands.
Every 10G SFP+ DWDM transceiver undergoes comprehensive laboratory validation to guarantee consistent signal transmission and stable hardware durability. Discover our full testing procedure at the LINK-PP Test Support Center.
Optical Spectrum Test
Verify center wavelength precision to maintain channel separation.
Eye Pattern Test
Analyze optical signal integrity to prevent waveform distortion.
Bit Error Rate Test
Ensure zero packet loss during continuous transmission.
Temperature Test
Validate operational stability across demanding thermal environments.
Product Shipping for Generic DW-SFP10G80-50-I Compatible LINK-PP 10G SFP+
Generic DW-SFP10G80-50-I Compatible LINK-PP 10G DWDM transceivers are packaged with dedicated protective materials to ensure complete physical integrity during transport. Streamlined order processing pairs with established express logistics channels to guarantee safe delivery worldwide.
Anti-Static Protective Packaging
Shield internal optical circuitry against electrostatic discharge risks.
Shock-Resistant Transport Protection
Protect optical transceivers against vibration during long transit.
Fast Order Processing and Dispatch
Process orders rapidly to get products ready for shipping.
Global Logistics and International Delivery
Coordinate trusted international carriers to ensure reliable delivery.
Plug the DW-SFP10G80-50-I optical transceiver into an SFP+ port, latch it securely, and connect standard duplex LC fibers. Ideal for industrial optical aggregation, this DWDM SFP+ transceiver aggregates separate 10G channels over long distances, keeping vital operational data running steadily through tough industrial environments.
DW-SFP10G80-50-I Technical Support
LINK-PP offers end-to-end technical support, from pre-sales consultation to post-deployment assistance, ensuring smooth integration and reliable network performance.
Pre-Sales Technical Consultation
Professional guidance to help you select the optimal DW-SFP10G80-50-I module for your network design and application needs.
Compatibility Verification Support
Validated compatibility with LINK-PP switches and other mainstream networking platforms for seamless deployment.
Deployment & Installation Assistance
Comprehensive step-by-step guidance for installation, configuration, and initial setup, ensuring accurate deployment and reliable, stable operation from the start.
Long-Term Technical Assurance
Ongoing technical support throughout the product lifecycle, delivering long-term stability for enterprise and carrier-grade networks.
Yes, provided it stays within its rated operating range of -40°C to +85°C. Make sure the cabinet provides adequate cooling, and the switch also remains within its own operating limits. by LINK-PP Technical Support
Use a compatible 100GHz DWDM MUX/DEMUX with a C50 (1537.40nm) port and sufficient channel isolation. Connect each module to its matching port so the system can keep neighboring channels properly separated. by LINK-PP Technical Support
Volume pricing may be available for larger orders. Please share your required quantity, and our sales team can provide a quote based on your order size. by LINK-PP Technical Support
Based on its minimum TX power of -1 dBm and receiver sensitivity of -23 dBm, the basic optical power budget is 22 dB before allowing for system margin. Include fiber, connector, splice, and MUX/DEMUX losses in your calculation, and leave additional margin for reliable operation. by LINK-PP Technical Support
Not necessarily. Existing single-mode fiber can still work well if its loss and dispersion meet the link requirements. Check the total optical loss, inspect and clean connector end faces, and verify dispersion for long-distance routes. by LINK-PP Technical Support
Good candidate for our regional cable operator network. The 1537.40nm wavelength matches the assigned DWDM channel, and the 10Gbps data rate meets our transport requirements.
