AA094688 is a 25G SFP28 single-mode optical transceiver module that engineered for precision data delivery, sustaining an ultra-lean maximum power consumption of 1.2W while driving 1310nm wavelengths across distances up to 10km with integrated DOM diagnostics.
Dell Part Number
AA094688
Vendor Name
LINK-PP
Form Factor
SFP28
Max Data Rate
25.78Gbps
Wavelength
1310nm
Max Cable Distance
10km
Connector
Duplex LC
Media
SMF
Transmitter Type
DFB
Receiver Type
PIN
Receiver Sensitivity
-13dBm
Receiver Overload
2dBm
TX Power
-8 to +3dBm
RX Power
-14 to +3dBm
DOM
Supported
Protocols
MSA Compliant, CPRI, eCPRI
Key Features of Dell AA094688 Compatible LINK-PP 25G SFP28
Dell AA094688 Compatible LINK-PP module is a 25GBASE-LR SFP28 optical transceiver designed for dependable single-mode fiber deployments. This module integrates a 1310nm wavelength and real-time DOM monitoring to ensure stable, long-distance data transmission up to 10km. It combines energy efficiency with high-speed connectivity to optimize modern network infrastructures.
This module is engineered for excellent thermal and energy efficiency in demanding environments. It features a 1.2W maximum power consumption with an established link, significantly reducing operational costs. The hot-pluggable SFP28 design also allows for easy installation and maintenance without disrupting network services.
AA094688: 25 Gbps Connectivity for High-Density Uplinks
This transceiver delivers a reliable 25Gbps data rate to meet the growing bandwidth demands of modern data centers. It provides a perfect migration path from standard 10G networks to faster, more scalable architectures. The increased throughput ensures efficient handling of high-density uplink traffic.
AA094688 Module with 1310nm Wavelength
Operating at a 1310nm optical wavelength, this module ensures minimal signal degradation over single-mode fiber. The chosen spectrum is ideal for local area networks and metropolitan transport systems. It utilizes advanced laser technology to maintain stable signaling across the entire link.
AA094688 Module Supporting 10km Transmission
Designed for long-distance transmission, this module reliably supports data transmission distances up to 10km. It is highly effective for connecting enterprise campuses, central offices, and distributed data center facilities. This long-reach capability eliminates the need for mid-span amplification.
AA094688 Module with Duplex LC/UPC Interface
The module comes equipped with an industry-standard duplex LC/UPC connector for secure fiber termination. This interface ensures low insertion loss and excellent back-reflection to protect signal integrity. Its compact connector design maximizes panel density in standard patch panels and switches.
AA094688 Module with DOM for Real-Time Monitoring
Featuring built-in Digital Optical Monitoring (DOM), this transceiver tracks vital operating parameters in real time. Network administrators can easily monitor transceiver temperature, supply voltage, and optical power levels. This proactive diagnostic tool helps prevent link failures and simplifies troubleshooting.
The Dell AA094688 Compatible LINK-PP 25G SFP28 module meets strict international quality standards, holding major industry certifications including ISO 9001, CE, RoHS, and FCC.
Every module undergoes rigorous hardware testing to ensure stable network performance before leaving the factory.
AA094688 Quality Certifications
These official compliance certificates guarantee that the transceiver adheres to global environmental, safety, and electromagnetic standards.
This product is in conformity with ISO9001. This system is valid to a company engaging in development, production and supply service of fiber optical products. Please contact us to learn more.
ISO/IEC 27001 is an international standard for managing and processing information security. This standard is jointly developed by the International Organization for Standardization (ISO) and the International Electrotechnical Commission (IEC). It sets out requirements for establishing, implementing, maintaining, and continually improving an information security management system (ISMS). Ensuring the confidentiality, integrity, and availability of organizational information assets, obtaining an ISO 27001 certificate means that the enterprise has passed the audit conducted by a certification body, proving that its information security management system has met the requirements of the international standard. Please contact us to learn more.
This product is in conformity with ISO14001.It is intended for use by an organization seeking to manage its environmental responsibilities in a systematic manner that contributes to the environmental pillar of sustainability. Please contact us to learn more.
ISO 45001 is a global standard that sets out the requirements for an occupational health and safety management system (OH&SMS).
REACH is a European Union regulation concerning the Registration, Evaluation, Authorization and Restriction of Chemicals. It came into force on 1st June 2007 and replaced a number of European Directives and Regulations with a single system. The regulation aims to protect human health and environmental safety, maintain and improve the competitiveness of the EU chemical industry, and develop innovative capabilities for non-toxic and harmless compounds to prevent market fragmentation, increase the transparency of the use of chemicals, promote non-animal experiments, and pursue sustainable social development.Please contact us to learn more.
This product meets the applicable requirements of Directive (EU) 2015/863 of RoHS. It restricts the use of 10 hazardous materials in the manufacture of various types of electronic and electrical equipment: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls, polybrominated diphenyl ethers, and four different phthalates. Please contact us to learn more.
This product fully accords with the FCC, which aims to manage the radio wave and magnetic fields more reasonably. Please contact us to learn more.
CB is an international system operated by IECEE. This product is based on IEC standards for testing the safety performance of electrical products. Please contact us to learn more.
This product fully accords with UKCA (UK Conformity Assessed) certificate, which signifies that it meets all relevant quality standards as well as health and safety requirements. Please contact us to learn more.
UL certification is a non-mandatory certification in the United States,mainly testing and certification of product safety performance.Its ultimate purpose is to obtain products with a fairly safe level for the market,and to contribute to ensuring human health and property safety.Please contact us to learn more.
AA094688 Certified for Reliable Host-Device Compatibility
The module is fully certified to work seamlessly across a wide range of major brand switches, routers, and servers without any interface issues.
Every SFP28 optical module undergoes extensive validation to guarantee stable high-speed data transmission, and you can explore our complete evaluation procedures at the LINK-PP Test Support Center.
Optical Spectrum Test
Verify precise laser wavelengths to ensure minimal signal degradation.
Eye Pattern Test
Analyze signal integrity to guarantee clean data transmission shapes.
Bit Error Rate Test
Measure data packet accuracy to confirm flawless network reliability.
Temperature Test
Evaluate thermal endurance to maintain stable performance under heat.
Product Shipping for Dell AA094688 Compatible LINK-PP 25G SFP28
We provide secure and efficient delivery services for all transceiver orders worldwide. Our team guarantees safe transit to protect your networking investments.
Anti-Static Protective Packaging
Shield delicate transceiver circuitry from harmful electrostatic discharge during handling.
Shock-Resistant Transport Protection
Safeguard optical components against severe vibrations during structural transit.
Fast Order Processing and Dispatch
Accelerate order fulfillment to ensure rapid turnaround times for customers.
Global Logistics and International Delivery
Deliver network hardware safely to worldwide destinations via trusted carriers.
Simply plug this hot-swappable optical module into any compatible 25G SFP28 slot and connect your duplex LC/UPC single-mode fiber cable. It immediately activates for high-density uplink routing, enterprise network backbones, and 5G wireless fronthaul deployments requiring dependable 10km data transmission.
AA094688 Technical Support
LINK-PP offers end-to-end technical support, from pre-sales consultation to post-deployment assistance, ensuring smooth integration and reliable network performance.
Pre-Sales Technical Consultation
Professional guidance to help you select the optimal AA094688 module for your network design and application needs.
Compatibility Verification Support
Validated compatibility with LINK-PP switches and other mainstream networking platforms for seamless deployment.
Deployment & Installation Assistance
Comprehensive step-by-step guidance for installation, configuration, and initial setup, ensuring accurate deployment and reliable, stable operation from the start.
Long-Term Technical Assurance
Ongoing technical support throughout the product lifecycle, delivering long-term stability for enterprise and carrier-grade networks.
LINK-PP provides after-sales support for the smooth deployment and reliable operation of the optical modules.
15-day no-reason return and refund
Free replacement for dead-on-arrival (DOA) or defective items within the initial period
Free repair services for manufacturing defects throughout the warranty period
Warranty exclusions and conditions apply
Dell AA094688 Compatible LINK-PP 25G SFP28 FAQ
Get clear answers about the laser architecture, connector types, signaling methods, and power efficiency of the AA094688 single-mode module.
The module incorporates a highly reliable Distributed Feedback (DFB) laser architecture, which maintains spectral stability across long distances under varying thermal loads.
No, the interface is explicitly designed for Duplex LC/UPC (Ultra Physical Contact) flat connectors. Forcing an APC-angled fiber plug into it will cause high insertion loss.
This module utilizes standard non-return-to-zero (NRZ) modulation at a serial line rate of 25.78Gbps, ensuring low latency compared to PAM4 optics.
Its ultra-lean 1.2W draw keeps the switch's overall thermal dissipation low, preventing port-throttling or cooling fans from ramping up to maximum velocity in fully populated 48-port switches.
Yes, the built-in DDM framework registers voltage, temperature, bias current, and optical power precisely according to SFF-8472 industry guidelines. by LINK-PP Technical Support
Yes, the module is fully engineered for hot-plugging, allowing clean physical installation without causing power spikes or interrupting adjacent data lanes. by LINK-PP Technical Support
No, both ends of the physical layer span must utilize matching 1310nm center wavelengths to successfully establish optical synchronization. by LINK-PP Technical Support
No, because modal dispersion is primarily a characteristic of multimode infrastructure. When operating at a 1310nm wavelength over standard single-mode fiber, chromatic dispersion is minimal, though legacy fiber quality and patch panel degradation should still be verified to ensure proper attenuation margins. by LINK-PP Technical Support
Accurate telemetry is crucial for our automated monitoring stack, and the DOM functions on these modules deliver exactly what we need. Rx/Tx power levels are stable and updating in real-time without glitching the system log.
