LS-MM8501-S5C operates as a commercial-grade 155M SFP module featuring an 850nm optical design and duplex LC interface for 550m transmissions, incorporating real-time Digital Diagnostic Monitoring (DDM) for instant diagnostics while operating between 0 and +70°C.
LINK-PP Part Number
LS-MM8501-S5C
Vendor Name
LINK-PP
Form Factor
SFP
Max Data Rate
155Mbps
Wavelength
850nm
Max Cable Distance
550m
Connector
Duplex LC
Media
MMF
Transmitter Type
VSCEL
Receiver Type
PIN
TX Power
-14 to -8dBm
RX Power
-32 to -6dBm
Receiver Sensitivity
-23dBm
DDM Support
Yes
Operating Temperature Range
0 to 70°C
Protocols
MSA Compliant
Key Features of LINK-PP LS-MM8501-S5C 155M SFP
LINK-PP LS-MM8501-S5C is a commercial-grade 155M SFP optical transceiver module that combines an 850nm wavelength and a duplex LC interface to support 550m multi-mode fiber transmissions. This hot-pluggable module integrates real-time digital diagnostics to ensure reliable, short-range network connectivity.
LINK-PP LS-MM8501-S5C 155M SFP Optical Module
This transceiver is equipped with a highly efficient 850nm VCSEL laser transmitter and a sensitive PIN photodiode receiver. Together, these optical components deliver reliable signal conversion and excellent electrical-to-optical conversion efficiency.
LS-MM8501-S5C: 155 Mbps Connectivity for Intra-Building LANs
Operating at a steady 155Mbps, this module provides the ideal data rate for Fast Ethernet networks. It is commonly deployed to support essential, stable data links within enterprise office buildings and campus local area networks.
LS-MM8501-S5C Module with 850nm Wavelength
The module utilizes an 850nm short-wavelength optical design optimized specifically for multi-mode fiber systems. This wavelength choice ensures low-cost dispersion characteristics, making it perfect for budget-friendly local data connections.
LS-MM8501-S5C Module Supporting 550m Transmission
Designed for short-reach infrastructure, this SFP safely covers link distances up to 550m over standard multi-mode fiber. It provides plenty of reach to easily span backbones between floor closets or nearby server racks.
LS-MM8501-S5C Module with Duplex LC Interface
Featuring an industry-standard duplex LC optical connector, this module ensures secure and straightforward fiber patching. Its small form-factor plug design allows for clean, high-density port layouts in busy network switches.
LS-MM8501-S5C Module with DDM for Real-Time Monitoring
With integrated Digital Diagnostic Monitoring (DDM), the module offers real-time telemetry of critical parameters like temperature, voltage, and optical power levels. Network administrators can easily use these diagnostics to proactively track link health and prevent unexpected downtime.
LINK-PP LS-MM8501-S5C 155M SFP Certification
The LINK-PP LS-MM8501-S5C optical module meets strict international standards, backed by essential regulatory approvals including ISO 9001, CE, RoHS, and FCC.
Every transceiver undergoes rigorous hardware verification, signal integrity tests, and environmental stress screening before leaving the factory.
LS-MM8501-S5C Quality Certifications
These industry-standard compliance credentials verify that the module meets strict safety, environmental protection, and manufacturing quality requirements.
This product is in conformity with ISO9001. This system is valid to a company engaging in development, production and supply service of fiber optical products. Please contact us to learn more.
ISO/IEC 27001 is an international standard for managing and processing information security. This standard is jointly developed by the International Organization for Standardization (ISO) and the International Electrotechnical Commission (IEC). It sets out requirements for establishing, implementing, maintaining, and continually improving an information security management system (ISMS). Ensuring the confidentiality, integrity, and availability of organizational information assets, obtaining an ISO 27001 certificate means that the enterprise has passed the audit conducted by a certification body, proving that its information security management system has met the requirements of the international standard. Please contact us to learn more.
This product is in conformity with ISO14001.It is intended for use by an organization seeking to manage its environmental responsibilities in a systematic manner that contributes to the environmental pillar of sustainability. Please contact us to learn more.
ISO 45001 is a global standard that sets out the requirements for an occupational health and safety management system (OH&SMS).
REACH is a European Union regulation concerning the Registration, Evaluation, Authorization and Restriction of Chemicals. It came into force on 1st June 2007 and replaced a number of European Directives and Regulations with a single system. The regulation aims to protect human health and environmental safety, maintain and improve the competitiveness of the EU chemical industry, and develop innovative capabilities for non-toxic and harmless compounds to prevent market fragmentation, increase the transparency of the use of chemicals, promote non-animal experiments, and pursue sustainable social development.Please contact us to learn more.
This product meets the applicable requirements of Directive (EU) 2015/863 of RoHS. It restricts the use of 10 hazardous materials in the manufacture of various types of electronic and electrical equipment: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls, polybrominated diphenyl ethers, and four different phthalates. Please contact us to learn more.
This product fully accords with the FCC, which aims to manage the radio wave and magnetic fields more reasonably. Please contact us to learn more.
CB is an international system operated by IECEE. This product is based on IEC standards for testing the safety performance of electrical products. Please contact us to learn more.
This product fully accords with UKCA (UK Conformity Assessed) certificate, which signifies that it meets all relevant quality standards as well as health and safety requirements. Please contact us to learn more.
UL certification is a non-mandatory certification in the United States,mainly testing and certification of product safety performance.Its ultimate purpose is to obtain products with a fairly safe level for the market,and to contribute to ensuring human health and property safety.Please contact us to learn more.
LS-MM8501-S5C Certified for Reliable Host-Device Compatibility
The module is extensively pre-tested in mainstream switches and routers to ensure seamless plug-and-play recognition without any configuration errors.
Rigorous Testing Ensures Reliable SFP Performance
Through comprehensive diagnostics, our engineering team ensures total hardware integrity and zero packet loss under heavy workloads. Learn more at the LINK-PP Test Support Center.
Optical Spectrum Test
Measure spectral width to prevent wavelength drift.
Eye Pattern Test
Audit optical waveform clarity for clean signal transitions.
Bit Error Rate Test
Confirm flawless packet delivery under full traffic loads.
Temperature Test
Monitor optical output stability during extreme thermal cycles.
Product Shipping for LINK-PP LS-MM8501-S5C 155M SFP
We secure and expedite every order to ensure your SFP optical transceivers arrive safely and on schedule.
Anti-Static Protective Packaging
Shield delicate internal circuitry from electrostatic discharge during handling.
Shock-Resistant Transport Protection
Safeguard physical components against structural damage during transit vibrations.
Fast Order Processing and Dispatch
Expedite warehouse handling to guarantee prompt shipment arrival timelines.
Global Logistics and International Delivery
Coordinate reliable carriers to reach international destinations quickly.
Deploying the LINK-PP LS-MM8501-S5C module involves a simple, hot-swappable plug-and-play installation into any standard SFP slot. This commercial module is widely utilized to power Fast Ethernet bridges, industrial control systems, and enterprise intra-building fiber networks across 550-meter spans.
LS-MM8501-S5C Technical Support
LINK-PP offers end-to-end technical support, from pre-sales consultation to post-deployment assistance, ensuring smooth integration and reliable network performance.
Pre-Sales Technical Consultation
Professional guidance to help you select the optimal LS-MM8501-S5C module for your network design and application needs.
Compatibility Verification Support
Validated compatibility with LINK-PP switches and other mainstream networking platforms for seamless deployment.
Deployment & Installation Assistance
Comprehensive step-by-step guidance for installation, configuration, and initial setup, ensuring accurate deployment and reliable, stable operation from the start.
Long-Term Technical Assurance
Ongoing technical support throughout the product lifecycle, delivering long-term stability for enterprise and carrier-grade networks.
A:
No, the LS-MM8501-S5C SFP optical transceiver supports hot-plugging. You can safely insert or remove the module while the switch is running without disrupting other ports. By
admin on
2026-05-13
A:
You need a multi-mode fiber patch cord with a Duplex LC connector. Single-mode cables or SC connectors will not plug in or work. By
admin on
2025-12-25
A:
Yes. This 155M SFP module uses an 850nm wavelength and can transmit data up to 550m over standard multi-mode fiber, so your 400-meter run is safe. By
admin on
2025-10-06
A:
We support growing businesses! While larger orders get deeper discounts, our MOQ for wholesale pricing is very flexible. Contact our sales team, and we will find a budget-friendly solution for you. By
admin on
2025-04-30
