CWDM-SFP-1370 operates as a 1370nm CWDM SFP module, delivering 1Gbps data rates via a DFB laser and PIN photodiode, while supporting up to 80km transmission over single-mode fiber within a 0 to +70°C temperature range. Real-time digital optical monitoring is embedded for precise tracking of Tx/Rx power, bias current, temperature, and voltage, ensuring full visibility into link health.
Extreme Part Number
CWDM-SFP-1370
Vendor Name
LINK-PP
Form Factor
SFP
Max Data Rate
1.25Gbps
Wavelength
1370nm
Max Cable Distance
80km
Connector
Duplex LC
Media
SMF
Transmitter Type
DFB
Receiver Type
PIN
TX Power
-1 to +4dBm
RX Power
-26 to -1dBm
Receiver Sensitivity
-26dBm
Receiver Overload
-1dBm
EMC (Electromagnetic Compatibility)
Supported
DOM
Supported
Operating Temperature Range
0 to 70°C
Protocols
SFP MSA、SFF-8472
Key Features of Extreme CWDM-SFP-1370 Compatible LINK-PP 1.25G SFP
Extreme CWDM-SFP-1370 Compatible LINK-PP module is a CWDM module rated for 1Gbps data rates over single-mode fiber, with 80km reach and a Duplex LC connector. It embeds DOM for live optical monitoring and follows SFP MSA specifications for physical and electrical interoperability.
This SFP transceiver adopts a hot-pluggable SFP footprint, enabling insertion and removal without system power-down. Its pinout, control logic, and electrical interface are fully compliant with the SFP Multi-Source Agreement (MSA), ensuring drop-in compatibility with standard host equipment and management software.
CWDM-SFP-1370: 1 Gbps Connectivity for Single-Mode Fiber Backbones
Designed for backbone applications, this transceiver delivers a 1Gbps line rate over single-mode fiber. It is well-suited for high-speed trunk links where stable, long-distance data transport is required.
CWDM-SFP-1370 Module with CWDM Technology for Fiber Efficiency
Incorporating CWDM technology, the module enables wavelength-division multiplexing on a single fibre pair. This conserves scarce fibre resources and reduces the need for additional cable installation in dense network environments.
CWDM-SFP-1370 Module with 1370nm Wavelength
Operating at the 1370nm channel, this module falls within the standard CWDM grid for coarse wavelength division. The specific centre wavelength ensures low crosstalk with adjacent channels when used in multi-wavelength systems.
CWDM-SFP-1370 Module Supporting 80km Transmission
Capable of driving signals up to 80km over standard single-mode fibre, this module suits metro and regional interconnects. The integrated DFB laser and PIN receiver work together to maintain link integrity across that distance.
CWDM-SFP-1370 Module with Duplex LC Interface
Featuring a duplex LC optical connector, the module offers a compact and reliable dual-fibre interface. This industry-standard receptacle allows quick plug-and-play connection to patch panels and distribution frames.
CWDM-SFP-1370 Module with DOM for Real-Time Monitoring
With built-in Digital Optical Monitoring (DOM), the module reports real-time values for Tx/Rx power, laser bias current, supply voltage, and internal temperature. These live data help network operators detect link degradation early and schedule preventive maintenance.
This CWDM-SFP-1370 1G SFP transceiver complies with major international standards, including ISO 9001, CE, RoHS, and FCC, to ensure safety and performance.
Every module undergoes strict physical and optical tests before shipping to guarantee long-term stability and reliability.
CWDM-SFP-1370 Quality Certifications
These official credentials confirm that the transceiver meets strict industry guidelines for safety, performance, and environmental protection.
This product is in conformity with ISO9001. This system is valid to a company engaging in development, production and supply service of fiber optical products. Please contact us to learn more.
ISO/IEC 27001 is an international standard for managing and processing information security. This standard is jointly developed by the International Organization for Standardization (ISO) and the International Electrotechnical Commission (IEC). It sets out requirements for establishing, implementing, maintaining, and continually improving an information security management system (ISMS). Ensuring the confidentiality, integrity, and availability of organizational information assets, obtaining an ISO 27001 certificate means that the enterprise has passed the audit conducted by a certification body, proving that its information security management system has met the requirements of the international standard. Please contact us to learn more.
This product is in conformity with ISO14001.It is intended for use by an organization seeking to manage its environmental responsibilities in a systematic manner that contributes to the environmental pillar of sustainability. Please contact us to learn more.
ISO 45001 is a global standard that sets out the requirements for an occupational health and safety management system (OH&SMS).
REACH is a European Union regulation concerning the Registration, Evaluation, Authorization and Restriction of Chemicals. It came into force on 1st June 2007 and replaced a number of European Directives and Regulations with a single system. The regulation aims to protect human health and environmental safety, maintain and improve the competitiveness of the EU chemical industry, and develop innovative capabilities for non-toxic and harmless compounds to prevent market fragmentation, increase the transparency of the use of chemicals, promote non-animal experiments, and pursue sustainable social development.Please contact us to learn more.
This product meets the applicable requirements of Directive (EU) 2015/863 of RoHS. It restricts the use of 10 hazardous materials in the manufacture of various types of electronic and electrical equipment: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls, polybrominated diphenyl ethers, and four different phthalates. Please contact us to learn more.
This product fully accords with the FCC, which aims to manage the radio wave and magnetic fields more reasonably. Please contact us to learn more.
CB is an international system operated by IECEE. This product is based on IEC standards for testing the safety performance of electrical products. Please contact us to learn more.
This product fully accords with UKCA (UK Conformity Assessed) certificate, which signifies that it meets all relevant quality standards as well as health and safety requirements. Please contact us to learn more.
UL certification is a non-mandatory certification in the United States,mainly testing and certification of product safety performance.Its ultimate purpose is to obtain products with a fairly safe level for the market,and to contribute to ensuring human health and property safety.Please contact us to learn more.
CWDM-SFP-1370 Certified for Reliable Host-Device Compatibility
The optical module is fully tested on multiple switch and router brands to ensure seamless plug-and-play network integration.
Rigorous Testing Ensures Reliable SFP Performance
Every CWDM-SFP-1370 SFP module undergoes strict quality checks to maintain low latency and stable signal transmission across diverse network environments. Discover our full validation methodology at the LINK-PP Test Support Center.
Optical Spectrum Test
Measure output optical wavelength and power to ensure complete compliance with standard optical specifications.
Eye Pattern Test
Analyze optical signal waveforms to evaluate high-speed transmission quality and ensure low jitter levels.
Bit Error Rate Test
Verify data transmission accuracy under heavy traffic loads to ensure zero packet loss during operation.
Temperature Test
Expose modules to extreme environmental conditions to validate reliable signal stability across temperature shifts.
Product Shipping for Extreme CWDM-SFP-1370 Compatible LINK-PP 1.25G SFP
We offer secure and reliable shipping services for the CWDM-SFP-1370 1G SFP optical transceiver. Our dedicated team ensures every product arrives safely and efficiently at its final destination.
Anti-Static Protective Packaging
Shield optical components using anti-static packaging to block electrostatic risks.
Shock-Resistant Transport Protection
Use sturdy outer boxes with protective internal layers to absorb sudden road shocks.
Fast Order Processing and Dispatch
Handle purchase orders fast to ensure quick warehouse pickup and prompt product release.
Global Logistics and International Delivery
Partner with global express freight carriers to deliver items safely to all destinations.
Align the CWDM-SFP-1370 1370nm CWDM transceiver with the target SFP port, push until latched, and connect duplex LC fiber patch cables. Designed for CWDM multiplexing, it optimizes data transmission in metro Ethernet rings, cloud data center interconnects, and high-density telecom aggregation infrastructure.
CWDM-SFP-1370 Technical Support
LINK-PP offers end-to-end technical support, from pre-sales consultation to post-deployment assistance, ensuring smooth integration and reliable network performance.
Pre-Sales Technical Consultation
Professional guidance to help you select the optimal CWDM-SFP-1370 module for your network design and application needs.
Compatibility Verification Support
Validated compatibility with LINK-PP switches and other mainstream networking platforms for seamless deployment.
Deployment & Installation Assistance
Comprehensive step-by-step guidance for installation, configuration, and initial setup, ensuring accurate deployment and reliable, stable operation from the start.
Long-Term Technical Assurance
Ongoing technical support throughout the product lifecycle, delivering long-term stability for enterprise and carrier-grade networks.
A:
Yes, the module has a duplex LC receptacle and is designed for single-mode fiber links. OS1 single-mode fiber is generally suitable, provided that the fiber condition, connector quality, and total optical loss are within the link budget. By
admin on
2026-03-31
A:
Yes, this 1370nm CWDM SFP is intended for CWDM wavelength-division applications and can be used with a compatible CWDM MUX/DEMUX. Make sure the multiplexer has a matching 1370nm channel and that the overall system loss, including MUX/DEMUX insertion loss, remains within the optical budget. By
admin on
2025-11-03
A:
Yes. This LS-CW371G-80C SFP module supports Digital Optical Monitoring under SFF-8472. If your switch or NMS supports DOM reading, you can monitor parameters such as module temperature, supply voltage, transmit optical power, and receive optical power to help identify abnormal operating conditions. By
admin on
2025-06-10
Installed these 1G SFP optical modules in our indoor server room environment. The commercial-grade thermal management holds up nicely, keeping operating temperatures consistently stable even with all adjacent SFP ports fully loaded. Hot-swapping was completely seamless.
Please write comments with more than three
character.
492578
446563
M***n
India
Verified
Purchase
5 .0
2026-03-30
We used this 1G 1370nm CWDM SFP to extend a connection between two office sites over existing single-mode fiber. The 80km rating gave us enough margin for our route, and the DOM values were visible from day one. Great fit for a practical enterprise fiber network build.
Please write comments with more than three
character.
492578
446564
D***n
Norway
Verified
Purchase
5 .0
2026-02-27
We needed a 1370nm single-mode SFP for a remote network cabinet connected to an indoor core room through a long metropolitan fiber route. The site was still within commercial operating conditions, but it experienced regular daytime temperature changes. This 1G CWDM optic maintained steady optical readings and clean connectivity throughout our monitoring period. The 80km distance capability also gave us enough allowance for connector loss, fusion splices, and future maintenance margin.
Please write comments with more than three
character.
492578
446567
K***h
Russian Federation
Verified
Purchase
4 .0
2026-02-04
Good protection for the actual transceivers, and each module was easy to identify after unboxing. The carton was a little scuffed from international transit, but the internal packaging did its job perfectly.
Please write comments with more than three
character.
492578
446569
I***e
United Kingdom
Verified
Purchase
5 .0
2026-01-22
Replaced some failed OEM modules on our edge aggregation layer with these units. They integrated cleanly with standard 9/125um G.652 single-mode fiber patch cables and established full-rate Gigabit Ethernet links right away. Solid performance at a fraction of the cost.
Please write comments with more than three
character.
492578
446561
P***y
Italy
Verified
Purchase
5 .0
2025-10-29
Our operations team used this 80km CWDM SFP during a fiber resilience project between two production facilities. We ran acceptance tests with long-duration traffic, link-state monitoring, and repeated module reseating before putting the circuit into service. The Duplex LC interface was convenient for our existing patch frames, and all modules reported normal temperature, voltage, TX power, and RX power through the switch diagnostics. No intermittent alarms or unstable links after deployment.
Please write comments with more than three
character.
492578
446558
S***d
Singapore
Verified
Purchase
4 .0
2025-06-18
The package was delayed briefly at customs, which was outside the supplier’s control. Once delivered, the 80km CWDM SFP modules were sealed properly and installed without any issue.
Please write comments with more than three
character.
492578
446568
C***y
France
Verified
Purchase
5 .0
2025-05-09
Using this 80km SFP CWDM module on our regional wireless tower relay link. The 1370nm wavelength keeps crosstalk non-existent across our 8-channel passive CWDM setup. Even during peak daytime traffic, latency and jitter remain completely flat.
Please write comments with more than three
character.
492578
446562
F***m
Spain
Verified
Purchase
5 .0
2025-04-01
We installed these LS-CW371G-80C 1370nm CWDM SFP modules for a regional security network connecting several remote camera aggregation sites back to the control center. Most paths were between 52km and 68km over single-mode fiber, with passive CWDM equipment already in place. The 1.25Gbps links stayed stable during continuous video traffic, and the DOM data gave our NOC useful visibility into optical receive levels. Great option for extending legacy 1G infrastructure without adding new fiber pairs.
