E1MG-100ZX-80 drives long-haul connectivity as a hot-pluggable, commercial-grade 155M SFP single-mode optical module that leverages a 1550nm wavelength to sustain robust Fibre Channel and Ethernet links across an impressive 80km span.
Brocade Part Number
E1MG-100ZX-80
Vendor Name
LINK-PP
Form Factor
SFP
Max Data Rate
155Mbps
Wavelength
1550nm
Max Cable Distance
80km
Connector
Duplex LC
Media
SMF
Transmitter Type
DFB
Receiver Type
PIN
TX Power
-14 to -8dBm
RX Power
-32 to -6dBm
Receiver Sensitivity
< -32dBm
DOM Support
Yes
Operating Temperature Range
0 to 70°C
Protocols
GR-468, MSA Compliant
Key Features of Brocade E1MG-100ZX-80 Compatible LINK-PP 155M SFP
Brocade E1MG-100ZX-80 Compatible LINK-PP module is a commercial-grade single-mode transceiver built to secure dependable long-range data links. This hot-pluggable module unifies a 1550nm optics core, a duplex LC port, and onboard telemetry to span long distances without signal degradation. It serves as an efficient hardware solution for standardizing telecommunication and storage network expansions.
This variant incorporates a 1550nm DFB laser that serves as a highly stable, low-noise light source for single-mode fiber infrastructure. Built in strict compliance with SFP MSA and SFF-8472 guidelines, it ensures instant plug-and-play compatibility across diverse host platforms. The specialized transmitter optics prevent pulse broadening to maintain clean eye diagrams over extended runs.
E1MG-100ZX-80: 155 Mbps Connectivity for Fiber Channel Infrastructure
This module delivers a steady 155Mbps data rate, tailored specifically to match the timing constraints of legacy storage architectures. It provides an uninterrupted, fixed-bandwidth pipeline that keeps enterprise Fibre Channel setups perfectly synchronized. This reliable bit rate prevents latency issues and buffer management errors in older-generation storage networks.
E1MG-100ZX-80 Module with 1550nm Wavelength
By operating in the 1550nm spectral band, the transceiver takes advantage of the absolute lowest attenuation point found in standard single-mode glass. This selection drastically cuts down on optical power loss per kilometer compared to shorter wavelengths. It allows clean, unamplified light propagation across complex regional fiber topologies.
E1MG-100ZX-80 Module Supporting 80km Transmission
Designed for long-haul operations, this device features a robust optical power budget engineered to bridge distances up to 80km. It eliminates the need for expensive intermediate repeaters or signal regenerators along the fiber path. This extensive reach makes it a cost-effective choice for linking distant corporate branches or rural sub-stations.
E1MG-100ZX-80 Module with Duplex LC Interface
The housing features a standardized duplex LC receptacle that establishes a firm, click-to-lock connection with matching fiber patch cables. Its precise mechanical alignment minimizes insertion loss and back-reflection at the optical mating plane. Additionally, the small form-factor design helps conserve valuable faceplate space on high-density switches.
E1MG-100ZX-80 Module with DOM for Real-Time Monitoring
Onboard Digital Optical Monitoring (DOM) gives technicians a continuous window into critical transceiver metrics. Through the host software, users can immediately view live operating temperatures, supply voltage, and precise laser power levels. This proactive diagnostic tool simplifies network troubleshooting and helps prevent unexpected link downtime.
The Brocade E1MG-100ZX-80 Compatible LINK-PP module is manufactured under strict international standards and carries full ISO 9001, CE, RoHS, and FCC certifications to guarantee safety, quality, and environmental compliance.
Each transceiver undergoes rigorous optical and environmental stress testing to ensure flawless performance before deployment.
E1MG-100ZX-80 Quality Certifications
These industry-standard compliance credentials verify that the module meets global safety requirements and environmental protection laws for electronic hardware.
This product is in conformity with ISO9001. This system is valid to a company engaging in development, production and supply service of fiber optical products. Please contact us to learn more.
ISO/IEC 27001 is an international standard for managing and processing information security. This standard is jointly developed by the International Organization for Standardization (ISO) and the International Electrotechnical Commission (IEC). It sets out requirements for establishing, implementing, maintaining, and continually improving an information security management system (ISMS). Ensuring the confidentiality, integrity, and availability of organizational information assets, obtaining an ISO 27001 certificate means that the enterprise has passed the audit conducted by a certification body, proving that its information security management system has met the requirements of the international standard. Please contact us to learn more.
This product is in conformity with ISO14001.It is intended for use by an organization seeking to manage its environmental responsibilities in a systematic manner that contributes to the environmental pillar of sustainability. Please contact us to learn more.
ISO 45001 is a global standard that sets out the requirements for an occupational health and safety management system (OH&SMS).
REACH is a European Union regulation concerning the Registration, Evaluation, Authorization and Restriction of Chemicals. It came into force on 1st June 2007 and replaced a number of European Directives and Regulations with a single system. The regulation aims to protect human health and environmental safety, maintain and improve the competitiveness of the EU chemical industry, and develop innovative capabilities for non-toxic and harmless compounds to prevent market fragmentation, increase the transparency of the use of chemicals, promote non-animal experiments, and pursue sustainable social development.Please contact us to learn more.
This product meets the applicable requirements of Directive (EU) 2015/863 of RoHS. It restricts the use of 10 hazardous materials in the manufacture of various types of electronic and electrical equipment: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls, polybrominated diphenyl ethers, and four different phthalates. Please contact us to learn more.
This product fully accords with the FCC, which aims to manage the radio wave and magnetic fields more reasonably. Please contact us to learn more.
CB is an international system operated by IECEE. This product is based on IEC standards for testing the safety performance of electrical products. Please contact us to learn more.
This product fully accords with UKCA (UK Conformity Assessed) certificate, which signifies that it meets all relevant quality standards as well as health and safety requirements. Please contact us to learn more.
UL certification is a non-mandatory certification in the United States,mainly testing and certification of product safety performance.Its ultimate purpose is to obtain products with a fairly safe level for the market,and to contribute to ensuring human health and property safety.Please contact us to learn more.
E1MG-100ZX-80 Certified for Reliable Host-Device Compatibility
Comprehensive firmware validation ensures the module is fully recognized and works seamlessly across a wide range of standard enterprise networking switches.
Rigorous Testing Ensures Reliable SFP Performance
We subject every transceiver to rigorous hardware evaluation to guarantee absolute link stability, with full diagnostic methodologies detailed on the LINK-PP Test Support Center.
Optical Spectrum Test
Verify precise central wavelengths to prevent cross-channel interference.
Eye Pattern Test
Evaluate transmitter signal distortion to confirm optimal waveform quality.
Bit Error Rate Test
Validate packet delivery accuracy under full line-rate stress.
Temperature Test
Ensure consistent hardware performance during variable thermal conditions.
Product Shipping for Brocade E1MG-100ZX-80 Compatible LINK-PP 155M SFP
We provide secure global logistics and rapid order turnaround, guaranteeing your optical transceivers arrive safely and on time.
Anti-Static Protective Packaging
Shield delicate module circuitry from dangerous electrostatic discharge.
Shock-Resistant Transport Protection
Safeguard optical alignments against physical vibrations during transit.
Fast Order Processing and Dispatch
Accelerate warehouse fulfillment to minimize your network deployment delay.
Global Logistics and International Delivery
Ship items worldwide through reliable international express freight carriers.
Simply plug the E1MG-100ZX-80 hot-pluggable 155M optical module into an active SFP slot for instant setup. It is optimized for long-haul Fiber Channel networks and legacy telecom backhauls, providing dependable data transmission across 80km spans in enterprise data centers and regional communication hubs.
E1MG-100ZX-80 Technical Support
LINK-PP offers end-to-end technical support, from pre-sales consultation to post-deployment assistance, ensuring smooth integration and reliable network performance.
Pre-Sales Technical Consultation
Professional guidance to help you select the optimal E1MG-100ZX-80 module for your network design and application needs.
Compatibility Verification Support
Validated compatibility with LINK-PP switches and other mainstream networking platforms for seamless deployment.
Deployment & Installation Assistance
Comprehensive step-by-step guidance for installation, configuration, and initial setup, ensuring accurate deployment and reliable, stable operation from the start.
Long-Term Technical Assurance
Ongoing technical support throughout the product lifecycle, delivering long-term stability for enterprise and carrier-grade networks.
A:
Yes, 1550nm light is more vulnerable to bending losses than 1310nm, so you must maintain the standard minimum bend radius for your SMF cabling. By
admin on
2026-03-02
A:
The transceiver can withstand non-operational ambient warehouse exposure ranging from -40°C up to +85°C without experiencing degradation of its internal optical components. By
admin on
2026-01-30
A:
Yes, the module constantly samples host supply voltage alongside optical metrics, flagging anomalies before physical link loss occurs. By
admin on
2025-12-10
A:
The DOM parameters are continuously updated on the transceiver's internal registry, allowing your network monitoring software to poll the physical data in real time. By
admin on
2025-11-12
A:
It depends on your total link budget; this module offers a robust power budget designed specifically to handle the attenuation of long-haul single-mode lines. By
